Open
Eject
Close
Tilt +
Tilt –
Exit
Open/Tilt
Detach
15
VOL
7
ENGLISH
Monitor panel/touch panel
Basic operations —
INTRODUCTION
• Turns on the power.
• Turns off the power. [Hold]
• Attenuates the sound (if the power is on).
Changes the sources.
☞ page 11
Remote sensor
Adjusts the volume.*
Resets the unit.
• Use only when the internal system malfunctions.
Displays <AV Menu> screen. ☞ page 59
Displays and erases the Short Cut windows. ☞ page 12
Changes the display information.
Displays <Source Menu> screen. ☞ page 11
• Activates/deactivates TA Standby Reception.
• Displays < PTy Search> menu. [Hold]
☞ pages 15 and 16
• Displays < Open/Tilt > menu. ☞ below
• Ejects the disc and displays <Open/Tilt > menu.
[Hold]
• Closes the monitor panel when < Open/Tilt > menu
is displayed.
To detach the monitor
panel.
<Open/Tilt > menu
• Shaded items cannot be used.
[Open] Opens the monitor panel.
[Eject] Ejects the disc.
[Close] Closes the monitor panel.
[Tilt +/– ] Tilts the monitor panel.
[Detach ] To detach the monitor panel.
[Exit] Erases this screen.
* You can also adjust the
volume by moving your
finger on the touch
panel as illustrated.
