LCD Monitor/Viewfinder
Indications
During Video Recording Only
1Tape Running Indicator ( pg. 18)
(Rotates while tape is running.)
2Selected Wide Mode Indicator ( pg. 17)
(only 16:9 indicator is displayed)
3Live Slow Indicator ( pg. 36)
4Recording Speed Mode (SP/LP) ( pg. 33)
(only LP indicator is displayed)
5Tape Remaining Time ( pg. 18)
6REC: (Appears during recording.)
( pg. 18)
SLOW
: (Appears when using Live Slow.)
( pg. 36)
7 : Insert ( pg. 45)
8 : Insert Pause
8Selected Wipe/Fader Effect Indicator
( pg. 40)
9Wind Cut Indicator ( pg. 33)
!Time Code ( pg. 34)
"Digital Image Stabiliser (“DIS”) ( pg. 32)
(only indicator is displayed)
#SOUND 12BIT/16BIT: Sound Mode
Indicator ( pg. 33) (Appears for approx. 5
seconds after turning on the camcorder.)
During Both Video And D.S.C. Recording
1Battery Remaining Power Indicator
2Operation Mode ( pg. 20)
A
: Auto Mode
M
: Manual Mode
3LED Light Indicator ( pg. 36)
4 : Night-Scope Indicator ( pg. 40)
: Gain Up Mode ( pg. 33)
5Shutter Speed ( pg. 41)
6White Balance Indicator ( pg. 39)
7Selected Effect Indicator ( pg. 41)
8Selected Program AE Indicator ( pg. 40)
9Approximate Zoom Ratio ( pg. 19)
!Zoom Indicator ( pg. 19)
"Shooting Icon ( pg. 26)
(Appears and blinks during shooting.)
#Card Icon ( pg. 26)
: Appears during shooting.
: Blinks in white when a memory card is
not loaded.
$Image Size/Picture Quality: 640 x 480 F
(FINE) and 640 x 480 S
(STANDARD) (in order of quality)
( pg. 33)
%Remaining Number Of Shots ( pg. 26)
(Displays the approximate remaining
number of shots that can be stored during
D.S.C. recording.)
&
: (Appears when taking Snapshot.)
( pg. 26, 36)
( : Spot Exposure Control Indicator
( pg. 38)
: Backlight Compensation Indicator
( pg. 38)
±: Exposure Adjustment Indicator
( pg. 38)
Iris Lock Indicator ( pg. 38)
)Date/Time ( pg. 15)
~Manual Focus Adjustment Indicator
( pg. 37)
LP
W
H
SOUND
12
BIT
– – –min
16:9
"
!
1
2
35
6
8
4
#
9
7
15:55
REC
3
10
x
M
)~
1
2
3
4
5
6
7
8
9
&
%
(
!
0
:
06
1
.
1
2
1
0
3
7
3
15
.
# $"
640
F
640
F
640
F
640
S
