EN11
Shoulder Strap Attachment
1
Make sure the battery pack is removed. Following the
illustration, thread the strap through the eyelet 1,
then fold it back and thread it through the buckle 2.
Repeat the procedure to attach the other end of the
strap to the other eyelet 3 located under the Grip
Strap . Confirm the strap is not twisted.
CAUTION:
When attaching the camera to a tripod, extend
its legs to stabilise the camcorder. It is not
advised to use small sized tripods. This may
cause damage to the unit by falling over.
1
To attach the camera to a tripod, align the direction
stud and screw to the mounting socket and stud hole
on the camera. Then tighten the screw clockwise.
Some tripods are not equipped with studs.
Tripod Mounting
2
1
3
To Next Page
