EN61
Controls
1 Monitor Open Button
[PUSH OPEN] ..................................... pg. 16
2 Dioptre Adjustment Control ................. pg. 10
3 Battery Release Switch
[BAT. RELEASE] ...................................... pg. 8
4 MENU Wheel [+, –, PUSH] ............... pg. 34
LCD Monitor BRIGHT
(Brightness) Control [+, –] .................. pg. 16
5 Snapshot Button [SNAPSHOT] ............. pg. 30
6 Power Zoom Lever [T/W] .................. pg. 18
Speaker Volume Control [VOL.] ........ pg. 20
7 FOCUS Button .................................. pg. 25
BLANK SEARCH Button .................... pg. 21
8 Stop Button [5] ................................. pg. 20
NIGHT-SCOPE Button ....................... pg. 26
9 Rewind Button [
2
] ......................... pg. 20
EXPOSURE Button ............................ pg. 32
0 Play/Pause Button [
4
/6] ................... pg. 20
Programme AE Button [P.AE] ............. pg. 26
! Fast-Forward Button [
3
] ................. pg. 20
BACKLIGHT Button .......................... pg. 32
@ Power Switch [ , , , OFF] ...... pg. 17
# Recording Start/Stop Button .................. pg. 16
$ Lock Button ......................................... pg. 17
% OPEN/EJECT Switch ............................. pg. 13
Connectors
The connectors ^ to ( are located beneath a cover.
^ S-Video Output Connector
[S] ........................................... pg. 22, 40, 46
& PC (DIGITAL PHOTO) Connector ........ pg. 51
* J Terminal [JLIP
(Joint Level Interface Protocol)] ............. pg. 46
Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
Software.
Connect the editing cable when performing
Random Assemble Editing ............ pg. 45 – 49
( Audio/Video Output Connector
[AV] ........................................ pg. 22, 40, 46
) DC Input Connector .......................... pg. 8, 9
q Digital Video Connector
[DV OUT] (i.Link*) .................. pg. 41, 51, 52
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
Indicators
w Tally Lamp ..................................... pg. 16, 36
e CHARGE Lamp ...................................... pg. 8
r Power Lamp .................................. pg. 16, 17
Other Parts
t Remote Sensor .................................. pg. 42
Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
y Viewfinder ........................................... pg. 10
u Stereo Microphone .............................. pg. 50
i Shoulder Strap Eyelets .......................... pg. 11
o Grip Strap ............................................ pg. 10
p Viewfinder Cleaning Hatch .................. pg. 65
Q Battery Pack Mount ............................... pg. 8
W LCD Monitor ................................. pg. 16, 17
E Speaker ............................................... pg. 20
R Stud Hole ............................................ pg. 11
T Tripod Mounting Socket ....................... pg. 11
