BATTERY PACK BN-V11U BN-V11U BN-V11U BN-V11U BN-V20BU
BODY COLOR Silver Silver Silver Metallic gray Metallic gray
DSC Used Used Used Not used Not used
LCD MONITOR 3" 2.5" 3" 2.5" 2.5"
PC CONNECTION CABLE Optional Provided Provided Optional Optional
VIEW FINDER Color Color Black/White Black/White Black/White
TABLE OF CONTENTS
DIFFERENT TABLE ....................................................................................................................................................................1 to 3
4. CHARTS AND DIAGRAMS
4.1 BOARD INTERCONNECTIONS ................................................................................................................................... 4-1
4.2 DSP SCHEMATIC DIAGRAM ....................................................................................................................................... 4-3
4.3 IRIS & AF/ZOOM SCHEMATIC DIAGRAM................................................................................................................... 4-5
4.4 REGULATOR SCHEMATIC DIAGRAM ........................................................................................................................ 4-7
4.5 LCD CTL SCHEMATIC DIAGRAM (FOR SXM735)...................................................................................................... 4-9
4.6 MAIN CIRCUIT BOARD ...............................................................................................................................................4-11
5. PARTS LIST
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ........................................................................................................ 5-1
5.2 FINAL ASSEMBLY <M2> .............................................................................................................................................. 5-3
5.3 ELECTRICAL PARTS LIST
MAIN BOARD ASSEMBLY <01> .................................................................................................................................. 5-6
The following table indicate main different points between models GR-SXM930U, SXM735U, SXM730U/UC, SXM330U and
GR-SXM335U.
MODEL
ITEM
The following table indicate different parts number between models GR-SXM930U, SXM735U, SXM730U/UC, SXM330U and
GR-SXM335U.
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5
1
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
1 PACKING CASE LY32179-005A LY32179-004A
7 REGIST.CARD/WARRANTY CARD BT-51020-2 BT-52004-1 BT-51020-2
! 11 BATTERY PACK YQ10629A LY31199-001A
14 CORE FILTER QQR0491-002 ––
15 PC CONNECTION CABLE QAM0084-001 ––
16 REMOTE CONTROL UNIT LY42129-001A –
18 AAA(R03)BATTERY,X2 Used Used Used Used Used Not Used
19 CD ROM * LY31133-001B LY32210-007A ––
20 POLY BAG * LY30023-010A – – – – –
21 SER.NET CARD – – – BT-20071B – –
22 SOFT WARE PERM. YU30843-4 ––
26 SHEET (INSTALL) LYT0309-004A ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U GR-SXM730UC GR-SXM330U GR-SXM335U
Note: Mark – is not used. Mark is same as left. Mark * reference model was also changed.
