FINAL ASSEMBLY <M2>
Note: Mark – is not used. Mark
is same as left. Mark * reference model was also changed.
MONITOR ASSEMBLY <M5>
REF. NO.
101 LOWER CASE ASSY LY20684-009A LY20684-008A
102 COVER(JACK) * LY31945-001B LY31945-001C * LY31945-001B LY31945-001C
104 FRONT COVER ASSY LY20683-015A LY20683-005B
105 CASS.COVER(M)ASSY * LY20694-002A LY20694-002B * LY20694-004A LY20694-004B
106 UPPER CASE(M) LY10257-018A LY10257-037A LY10257-036A LY10257-015A LY10257-039A
109 TOP OPE UNIT LY20614-008B LY20614-012B
114 STICKER(D) LY32061-004A LY32061-005A
115 SCREW * QYSLSF2060D,X5 QYSLSF2060D,X4 * QYSLSF2060D,X5 QYSLSF2060D,X4
136 SCREW/SPECIAL SCREW * QYSLSF2060D LY42981-001A * QYSLSF2060D LY42981-001A
154 HOLDER(DSC P.) LY20645-001A ––
155 SCREW QYSLSF2060D ––
156 FPC(DSC)ASSY LY42875-001A ––
156A S.SHEET(DSC FPC) LY42876-001A ––
157 INSULATER YU40341 ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
ELECTRONIC VIEWFINDER ASSEMBLY <M4>
REF. NO.
! 300 E.VF ASSY LYH20242-001A –––
303 SPACER(HOLDER) * LY42221-001C LY43013-001A –––
! 350 E.VF ASSY ––LY20701-001A
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
! 500 MONITOR ASSY * LYH20217-014A LYH20217-019B LYH20217-014B * LYH20217-015A LYH20217-005B
! 501 M.COVER ASSY LY20679-008A LY20679-009A
502 M.CASE(3/2.5)ASSY LY32035-001A LY32036-001A LY32035-001A LY32036-001A
504 HINGE COVER(U) LY31939-001A LY31939-004A
515 HOLDER(3/2.5PWB) LY20647-001A LY20672-001B LY20647-001A LY20672-001B
519 BACK LIGHT QLL0094-001 QLL0093-001 QLL0094-001 QLL0093-001
520 LCD MODULE QLD0118-001 QLD0176-001 QLD0118-001 QLD0176-001
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
MAIN BOARD ASSEMBLY <01>
REF. NO.
PW MAIN BOARD ASSY YB10310UG-02 YB10310VA YB10310UZ YB10310UD-01 YB10310UY
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
