C-VF BL BOARD ASSEMBLY <06>
MONITOR BOARD ASSEMBLY <07>
DSC BOARD ASSEMBLY <08>
E.VF BOARD ASSEMBLY <60>
Note: Mark – is not used. Mark
is same as left. Mark * reference model was also changed.
REF. NO.
PW C-VF BL BOARD ASSY YB20901A –––
R7562 MG RESISTOR * NRSA63J-470X NRSA63J-360X –––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
PW MONITOR BOARD ASSY * YB20900A-01 YB20900D YB20900C * YB20900B-01 YB20900D
IC7501 IC * TC7WH34FK ––* TC7WH34FK –
R7511,R7512 MG RESISTOR NRSA63J-223X – NRSA63J-223X ––
R7513 MG RESISTOR – NRSA63J-103X – NRSA63J-103X
R7514 MG RESISTOR NRSA63J-333X – NRSA63J-333X ––
R7515 MG RESISTOR NRSA63J-562X NRSA63J-302X NRSA63J-562X NRSA63J-302X
R7519 to R7521
MG RESISTOR * – NRSA63J-0R0X * – NRSA63J-0R0X
C7502 CAPACITOR * NCB31EK-103X ––* NCB31EK-103X –
C7510 CAPACITOR NCB31EK-103X – NCB31EK-103X ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
PW DSC BOARD ASSY YB20898B ––
WR1
E-SI C WIRE C-F,JP8001/JP8002
* WJM0179-001A WJM0179-001B ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
PW E.VF BOARD ASSY ––LY41289-002A
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
To Next Page
