JVC KD-BT11 User Manual

ENGLISH
16
Listening to the other external components
You can connect an external component to the AUX (auxiliary) input jack on the control panel.
1
Select “AUX IN.”
2
—
Turn on the connected component and start playing the source.
3
Adjust the volume.
4
—
Adjust the sound as you want (see pages 18 and 19).
Connecting an external component to the AUX input jack
3.5 mm stereo mini plug
(not supplied)
Portable audio player, etc.
EN08-17_KD-BT11[EE]_3.indd 16EN08-17_KD-BT11[EE]_3.indd 16 11/30/07 4:41:05 PM11/30/07 4:41:05 PM

JVC KD-BT11 Specifications

General

MP3 playback	Yes
DVD Audio playback	No
FM band range	87.5 - 108 MHz
LW band range	144 - 279 kHz
Output power	50 W
Frequency range	16 - 20000 Hz
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	98 dB
File type	MP3/WMA

Weight and Dimensions

Dimensions (WxDxH)	182 x 52 x 159.5 mm
