SETTINGS
Indications Item
( : Initial)
Setting, [reference page]
DIMMER
Dimmer
• AUTO
• ON
• OFF
: Dims the display and button illumination when you turn on the
headlights.
: Activates dimmer.
: Cancels.
SCROLL *
2
Scroll
• ONCE
• AUTO
• OFF
: Scrolls the displayed information once.
: Repeats scrolling (at 5-second intervals).
: Cancels.
• Pressing DISP for more than one second can scroll the display
regardless of the setting.
L/O MODE
Line output mode
• REAR
• SUB.W
: Select if the REAR LINE OUT terminals are used for connecting the rear
speakers (through an external amplifier).
: Select if the REAR LINE OUT terminals are used for connecting a
subwoofer (through an external amplifier).
SUB.W FREQ *
3
Subwoofer cutoff
frequency
• LOW
• MID
• HIGH
: Frequencies lower than 90 Hz are sent to the subwoofer.
: Frequencies lower than 135 Hz are sent to the subwoofer.
: Frequencies lower than 180 Hz are sent to the subwoofer.
SUB.W PHASE *
3
Subwoofer phase
• 180 DEG
• 0 DEG
: Select either “0 DEG” or “180 DEG” which reproduces a better sound.
EXT INPUT *
4
External input
• CHANGER
• EXT INPUT
: To connect a JVC CD changer, [15], or an Apple iPod, [16].
: To connect portable audio player to the CD changer jack, [17].
TAG DISPLAY
Tag display
• TAG ON
• TAG OFF
: Shows the Tag information while playing MP3/WMA tracks.
: Cancels.
AMP GAIN
Amplifier gain
control
• LOW POWER
• HIGH POWER
: VOLUME 00 – VOLUME 30. (Select this if the maximum power of the
speaker is less than 50 W to avoid damaging the speaker.)
: VOLUME 00 – VOLUME 50.
IF BAND
Intermediate
frequency band
• AUTO
• WIDE
: Increases the tuner selectivity to reduce interference noises between
adjacent stations. (Stereo effect may be lost.)
: Subject to interference noises from adjacent stations, but sound
quality will not be degraded and the stereo effect will remain.
*
2
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*
3
Displayed only when “L/O MODE” is set to “SUB.W.”
*
4
Displayed only when one of the following sources is selected—FM, AM, CD, BLUETOOTH, AUX IN.
EN16-21_KD-BT11_001A_1.indd 21EN16-21_KD-BT11_001A_1.indd 21 10/31/07 6:06:32 PM10/31/07 6:06:32 PM

JVC KD-BT11 Specifications

General

MP3 playback	Yes
DVD Audio playback	No
FM band range	87.5 - 108 MHz
LW band range	144 - 279 kHz
Output power	50 W
Frequency range	16 - 20000 Hz
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	98 dB
File type	MP3/WMA

Weight and Dimensions

Dimensions (WxDxH)	182 x 52 x 159.5 mm
