3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3005-001 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
9 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 QYSDSF2006M SCREW 2mm x 6mm(x2)
12 GE30823-001A F. CHASSIS ASSY
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 FSYH4036-098 SHEET
15 GE30827-002A OPEN LEVER
16 GE30824-002A LOCK LEVER(O.L)
17 GE31245-001A RELEASE LEVER
18 GE30829-001A LOCK LEVER(TOP)
19 GE30825-002A LOCK LEVER(L)
20 GE30828-002A LOCK LEVER(R)
21 GE40154-001A GEAR
22 QZW0108-002 OIL DAMPER
23 GE40153-001A T.SPRING
24 GE40157-001A T.SPRING
25 VKW5264-005 T.SPRING
26 FSKW4012-002 T.SPRING
27 VKW5263-002 T.SPRING
28 GE40155-001A T.SPRING
29 QYSDSF2006M SCREW 2mm x 6mm
30 GE40156-001A BLIND
31 GE10080-004A FRONT PANEL
G301
E,G30
1EX
31 GE10080-001A FRONT PANEL
G302
E,G30
2EX
32 GE31048-007A FINDER ASSY
G301
E,G30
1EX
32 GE31048-008A FINDER ASSY
G302
E,G30
2EX
33 GE31044-001A POWER BUTTON
34 GE31038-001A VOLUME KNOB
35 GE40218-002A SHEET
36 GE31039-003A SEL BUTTON
37 FSYH4036-053 SHEET
38 GE31040-001A RIM LENS
39 FSYH4036-069 SHEET
40 GE31029-001A D.FUNC BTN
41 GE20161-001A PRESET BUTTON
42 GE31043-001A UP/DOWN BTN
43 GE31028-003A SSM BTN
44 GE31025-001A SEARCH BTN
45 GE31041-004A EJECT BUTTON
G301
E,G30
1EX
45 GE31041-001A EJECT BUTTON
G302
E,G30
2EX
46 GE31250-001A EJECT COVER
47 GE40220-001A LIGHT SHIELD
48 GE31042-004A DETACH BTN
G301
E,G30
1EX
48 GE31042-001A DETACH BTN
G302
E,G30
2EX
49 GE31045-001A RIM COVER
50 GE40204-001A JVC BADGE
51 VKW3001-330 COMP.SPRING
52 GE40202-004A COMP.SPRING
53 GE10081-001A REAR COVER
54 VKZ4777-001 MINI SCREW (x4)
55 GE31035-001A LCD CASE
56 GE31036-001A LCD LENS
57 GE31037-001A LENS CASE
58 GE40200-004A LIGHTING SHEET
G301
E,G30
1EX
58 GE40200-003A LIGHTING SHEET
G302
E,G30
2EX
59 GE40200-005A LIGHTING SHEET
G301
E,G30
1EX
60 GE31106-001A NAME PLATE
G301
E,G30
1EX
60 GE31103-001A NAME PLATE
G302
E,G30
2EX
61 LV41843-002A LASER CAUTION
62 QLD0290-001 LCD MODULE
G301
E,G30
1EX
62 QLD0322-001 LCD MODULE
G302
E,G30
2EX
63 QNZ0442-001 LCD CONNECTOR
64 QMFZ047-150-T FUSE 15A
65 GE30912-005A REAR BRACKET
66 QYSDST2606Z SCREW 2.6mm x 6mm
67 QYSDST2606Z SCREW 2.6mm x 6mm
68 QYSDST2606Z SCREW 2.6mm x 6mm
69 QYSDSF2606Z SCREW 2.6mm x 6mm
70 GE40172-004A IC BRACKET
71 GE40103-003A REG BRACKET
72 GE40107-002A HEAT SINK
73 GE30854-001A LED HOLDER
74 QAM0565-001 STEERING REMOTE
