3-6
Electrical parts list
Main board
Block No. [0][1][0][0]
Symbol No.
Part No. Part Name Description Local
IC 31 T B 211 8F -X P L L I C
IC71 SAA6579T-X IC
IC161 TEA6320T-X IC
IC301 LA47515 IC
IC501 TA2157FN-X RF AMP IC
IC521 TC94A14FA CD LSI IC
IC561 LA6242H-X IC
IC571 NJM4565M-WE IC
IC701 UPD784215AGC242 IC
IC702 IC-PST3433U-X IC
IC703 BR24L16F-W-X IC
IC801 HD74HC126FP-X IC
IC901 AN80T07 IC
Q1 UN2211-X TRANSISTOR
Q2 2SD601A/QR/-X TRANSISTOR
Q3 UN2111-X TRANSISTOR
Q4 2SB709A/R/-X TRANSISTOR
Q5 2SB624/4/-X TRANSISTOR
Q6 UN2211-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q51 2SD601A/QR/-X TRANSISTOR
Q52 2SD601A/QR/-X TRANSISTOR
Q53 UN2211-X TRANSISTOR
Q71 UN2111-X TRANSISTOR
Q73 2SD601A/QR/-X TRANSISTOR
Q74 2SD601A/QR/-X TRANSISTOR
Q241 2SD601A/QR/-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q501 2SB1241/QR/-T TRANSISTOR
Q521 UN2111-X TRANSISTOR
Q522 UN2211-X TRANSISTOR
Q561 2SB1322/RS/-T TRANSISTOR
Q773 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2211-X TRANSISTOR
Q783 UN2111-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q901 2SB709A/QR/-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MA111-X SI DIODE
D4 MA111-X SI DIODE
D71 MA111-X SI DIODE
D161 MA111-X SI DIODE
D171 MA111-X SI DIODE
D241 RB160M-30-X SB DIODE
D242 MA111-X SI DIODE
D243 UDZS5.1B-X Z DIODE
D321 MA111-X SI DIODE
D341 MA111-X SI DIODE
D561 1A3G-T1 SI DIODE
D701 MA111-X SI DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
D710 MA8062/M/-X Z DIODE
D711 MA8062/M/-X Z DIODE
D761 SML-310VT/JK/-X LED
G301
E,G30
1EX
D761 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D762 SML-310VT/JK/-X LED
G301
E,G30
1EX
D762 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D763 SML-310VT/JK/-X LED
G301
E,G30
1EX
D763 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D764 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D780 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D783 UDZS11B-X Z DIODE
D891 MA111-X SI DIODE
D892 MA111-X SI DIODE
D901 1N5401-TU-15 DIODE
D902 RB160M-30-X SB DIODE
D903 RB160M-30-X SB DIODE
D904 MA111-X SI DIODE
C2 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C3 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C8 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C31 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C42 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C50 NDC31HJ-101X C CAPACITOR 100pF 50V J
C51 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C52 NCB31EK-472X C CAPACITOR 4700pF 25V K
C53 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C54 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C55 NDC31HJ-331X C CAPACITOR 330pF 50V J
C71 NDC31HJ-820X C CAPACITOR 82pF 50V J
C72 NDC31HJ-470X C CAPACITOR 47pF 50V J
C73 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C74 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C75 NDC31HJ-561X C CAPACITOR 560pF 50V J
C76 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C77 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C78 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C79 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C81 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C82 NCB31HK-102X C CAPACITOR 1000pF 50V K
C83 NCB31HK-152X C CAPACITOR 1500pF 50V K
C84 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C91 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C92 NCB31HK-102X C CAPACITOR 1000pF 50V K
C93 NCB31HK-152X C CAPACITOR 1500pF 50V K
C94 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C162 NCB31HK-822X C CAPACITOR 8200pF 50V K
