Front board
Block No. [0][2][0][0]
R708 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R709 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R710 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R711 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R712 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R713 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R714 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R715 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R716 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R717 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R718 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R719 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R720 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R721 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R722 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R723 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R724 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R725 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R726 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R727 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R728 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R729 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R730 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R731 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R732 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R733 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R734 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R735 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R736 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R737 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R738 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R743 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R744 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R745 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R746 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R747 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R748 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R750 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R751 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R752 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R754 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R761 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R762 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R763 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R764 NRS181J-271X MG RESISTOR 270
Ω
1/8W J
R771 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R772 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R773 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R777 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R778 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R779 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R782 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R783 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R784 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R801 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R802 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R803 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R804 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R805 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R806 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R807 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R808 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R809 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R810 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R891 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R892 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R903 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R904 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R905 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R906 NRSA02J-822X MG RESISTOR 8.2k
Ω
1/10W J
R907 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
L1 QQL244J-4R7Z INDUCTIOR 4.7uH J
L521 QQL244J-4R7Z INDUCTIOR 4.7uH J
L522 QQL244J-4R7Z INDUCTIOR 4.7uH J
L523 QQL244J-470Z COIL 47uH J
Symbol No.
Part No. Part Name Description Local
L524 QQL244J-4R7Z INDUCTIOR 4.7uH J
L701 QQL244K-4R7Z COIL 4.7uH K
L702 QQL244K-4R7Z COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QNZ0605-001 CAR CONNECTOR
CN702 QGA2006F1-02 CONNECTOR W-B (1-2)
CN901 QNZ0650-001 CAR CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J301 QNN0519-001 SURROUND JACK
J801 QNZ0095-001 CONNECTOR
PP1 QZW0010-001 STYLE PIN
PP2 QZW0010-001 STYLE PIN
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSW1049-001Z TACT SWITCH
TU1 QAU0313-001 TUNER
X31 QAX0776-001Z CRYSTAL
X71 QAX0263-001Z CRYSTAL 4.332MHz
X521 QAX0413-001Z CRYSTAL 16.9344MHz
X701 QAX0777-001Z CRYSTAL
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC601 LC75823W IC
IC602 RPM7338-V4 REMOCON RCV
Q640 2SB624/4/-X TRANSISTOR
Q641 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
G301
E,G30
1EX
D601 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D602 SML-310VT/JK/-X LED
G301
E,G30
1EX
D602 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D603 SML-310VT/JK/-X LED
G301
E,G30
1EX
D603 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D604 SML-310VT/JK/-X LED
G301
E,G30
1EX
D604 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D605 SML-310VT/JK/-X LED
G301
E,G30
1EX
D605 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D606 SML-310VT/JK/-X LED
G301
E,G30
1EX
D606 LNJ308G81/1-3/X LED
G302
E,G30
2EX
D607 SML-310VT/JK/-X LED
G301
E,G30
1EX
D607 LNJ308G81/1-3/X LED
G302
E,G30
2EX
