Audio Amplifier Specifications| maximum power output front | 50 W per channel |
|---|---|
| maximum power output rear | 50 W per channel |
| continuous power output RMS front | 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion |
| continuous power output RMS rear | 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion |
| load impedance | 4 Ω (4 Ω to 8 Ω allowance) |
| equalizer control range frequencies | 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz, 6 kHz, 12 kHz |
| equalizer control range level | ±10 dB |
| frequency response | 40 Hz to 20 000 Hz |
| signal-to-noise ratio | 70 dB |
| line-out level/impedance | 5.0 V/20 kΩ load (full scale) |
| output impedance | 1 kΩ |
CD Player Specifications| operating voltage | DC 14.4 V (11 V to 16 V allowance) |
|---|---|
| allowable operating temperature | 0°C to +40°C |
| dimensions (W × H × D) installation size | 182 mm × 52 mm × 159 mm |
| dimensions (W × H × D) panel size | 188 mm × 58 mm × 12 mm |
| mass | 1.6 kg (excluding accessories) |
| frequency response | 5 Hz to 20 000 Hz |
| dynamic range | 96 dB |
| signal-to-noise ratio | 98 dB |
| max. bit rate mp3 | 320 Kbps |
| max. bit rate wma | 192 Kbps |
Tuner Specifications| frequency range FM | 87.5 MHz to 108.0 MHz |
|---|---|
| frequency range AM (MW) | 522 kHz to 1 620 kHz |
| frequency range AM (LW) | 144 kHz to 279 kHz |
| usable sensitivity FM | 11.3 dBf (1.0 µV/75 Ω) |
| 50 dB quieting sensitivity FM | 16.3 dBf (1.8 µV/75 Ω) |
| alternate channel selectivity FM (400 kHz) | 65 dB |
| frequency response FM | 40 Hz to 15 000 Hz |
| stereo separation FM | 30 dB |
| capture ratio FM | 1.5 dB |
| sensitivity MW | 20 µV |
| selectivity MW | 35 dB |
| sensitivity LW | 50 µV |
