60
ENGLISH
Selecting the playback modes
To play back tracks at random
(Random Play)
1 Press M MODE during play.
Mode appears on the display.
The next-step-operation buttons
start flashing.
2 Press number button 3 repeatedly while
Mode is still on the display.
Each time you press the button, random play
mode changes as follows:
For MP3 discs:
For CDs:
Mode
Active
Plays at random
indicator
Random All tracks of the
Folder* (folder random) current folder, then
indicator tracks of the next
lights up. folder and so on.
Random All tracks of
Disc (disc random) the current (or
indicator lights specified) disc.
up.
Random All tracks of
All (all random) all discs inserted in
indicator lights the magazine.
up.
Ex.: When you select Repeat Track while
playing an MP3 disc
Note:
MP3 indicator also lights up if the current playing
disc is an MP3 disc.
To cancel random play, select Random Off by
pressing number button 3 repeatedly or press
number button 4 in step 2.
To play back tracks repeatedly
(Repeat Play)
1 Press M MODE during play.
Mode appears on the display.
The next-step-operation buttons
start flashing.
2 Press number button 2 repeatedly while
Mode is still on the display.
Each time you press the button, repeat play
mode changes as follows:
For MP3 discs:
For CDs:
Ex.: When you select Random Disc while
playing an MP3 disc
* “Random Folder” is only applicable for MP3 disc.
EN56-61_KD-LH401[E_EX]f.p65 30/1/04, 5:23 PM60

Table of Contents

Other manuals for JVC KD-Lh401

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-Lh401 and is the answer not in the manual?

JVC KD-Lh401 Specifications

Audio Amplifier Specifications IconAudio Amplifier Specifications
maximum power output front50 W per channel
maximum power output rear50 W per channel
continuous power output RMS front19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output RMS rear19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range frequencies60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz, 6 kHz, 12 kHz
equalizer control range level±10 dB
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance5.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Specifications IconCD Player Specifications
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (W × H × D) installation size182 mm × 52 mm × 159 mm
dimensions (W × H × D) panel size188 mm × 58 mm × 12 mm
mass1.6 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate mp3320 Kbps
max. bit rate wma192 Kbps
Tuner Specifications IconTuner Specifications
frequency range FM87.5 MHz to 108.0 MHz
frequency range AM (MW)522 kHz to 1 620 kHz
frequency range AM (LW)144 kHz to 279 kHz
usable sensitivity FM11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity FM16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity FM (400 kHz)65 dB
frequency response FM40 Hz to 15 000 Hz
stereo separation FM30 dB
capture ratio FM1.5 dB
sensitivity MW20 µV
selectivity MW35 dB
sensitivity LW50 µV
