JVC KD-R35

24 ENGLISH
Specifications
AUDIO AMPLIFIER SECTION
Maximum Power Output: Front/
Rear:
50 W per channel
Continuous Power Output (RMS): Front/
Rear:
19 W per channel into 4 Ω, 40 Hz to
20 000 Hz at no more than 0.8% total
harmonic distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range: Bass: ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)
Q1.0, Q1.25, Q1.5, Q2.0
Middle: ±12 dB (0.5 kHz, 1.0 kHz, 1.5 kHz, 2.5 kHz)
Q0.75, Q1.0, Q1.25
Treble: ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz,
17.5 kHz)
Q (Fixed)
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance: Except
KD-R35:
2.5 V/20 kΩ load (full scale)
Subwoofer-Out Level/Impedance: Except
KD-R35:
2.5 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
Other Terminal: • AUX (auxiliary) input jack, Aerial input
• For KD-R412/KD-R411: Steering wheel remote
input, USB input Jack
• For KD-R35: USB input Jack
TUNER SECTION
Frequency Range: FM: 87.5 MHz to 108.0 MHz
AM: MW: 522 kHz to 1 620 kHz
LW: 144 kHz to 279 kHz
FM Tuner: Usable Sensitivity: 9.3 dBf (0.8 μV/75 Ω)
50 dB
Quieting Sensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel
Selectivity (400 kHz):
65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 40 dB
MW Tuner: Sensitivity: 20 μV
Selectivity: 40 dB
LW Tuner: Sensitivity: 50 μV
