1-22 (No.MA465<Rev.003>)
4.8 Tuner service mode
Key operation (FM and AM mode)
Enter service mode: [SEL] → [MENU] (3 sec)
Exit service mode: press [ENTER] (SEL) key.
Go to next item: press [DISP] key
Back to previous item: press [BACK] key
VER=#*** MICON version display
# indicates destination: J=USA, U=OTHERS (eg. ASIA), R=EUROPE, E=EASTERN EUROPE
*** indicates version No.
CD6V#### CD module version display.
######## Tuner device and version identification display
Display :TOM V3 for TOMIC V3 tuner.
Display: ATOM V5 for ATOMIC V5 tuner.
TINJ= ## Tuner injection indicator
"##" indicates current tuner injection.
PI =#### PI display of receiving station, "####" indicates PI code.
PTY=## PTY display of receiving station (00~29), "##" indicates PTY code.
TP=#TA=* TP, TA display of receiving station
"#" indicates TP ON/OFF: 1=ON; 0=OFF;
"*" indicates TA ON/OFF: 1=ON; 0=OFF.
MS=#DI=* M/S, DI display of receiving station
"#" indicates M/S ON/OFF: 1=ON; 0=OFF;
"*" indicates DI ON/OFF: 1=ON; 0=OFF.
AF=#### Display the contents of AF memory (by scrolling) "####" indicate AF frequencies.
FOR RDS ONLY
LEV= ##H Field strength indicator.
U&W= ##H Adjacent and Multi path noise level indicator.
IFC= ##H IF COUNTER result indicator.
IFBW= # FM IF filter bandwidth indicator.
RFAGC=## FM RF AGC resulting attenuation.
IFAGC=## FM IF AGC resulting attenuation.
##** CLOCK display of receiving station (Original DISP key operation)
######## FOR RDS ONLY
PS NAME display of receiving station (Original DISP key operation)
##### FREQUENCY display of receiving station (Original DISP key operation)
To Next Page
