ENGLISH
BASICS
To On the faceplate
Turn on the power Press .
• Press and hold to turn off the power.
Adjust the volume Press
.
• Press and hold
to continuously increase the volume to 15.
Press
to mute the sound or pause playback.
• Press again to cancel. The volume level returns to the previous level before muting or pause.
Select a source • Press
repeatedly.
• Press
, then press within 2 seconds.
Change the display information
Press
repeatedly.
( 16)
Select an item
1 Press to select an item.
2 Press to confirm.
Attach
How to reset
Detach
Faceplate for KD-R498/KD-R496/KD-R491
Your preset adjustments will
be erased except stored radio
stations.
Loading slot Display window
Detach button
Source button
Remote sensor
(Do not expose to
bright sunlight.)
