13
ENGLISH
Adjusting the sound
You can adjust the treble/bass sound and the speaker balance.
1
2
Equalization pattern changes as
you adjust the bass or treble.
Equalization pattern indicator
SOUND ADJUSTMENTS
1
Select the item you want to adjust.
Indication To do: Range
BAS Adjust the bass –6 (min.) — +6 (max.)
(Bass)
TRE Adjust the treble –6 (min.) — +6 (max.)
(Treble)
FAD Adjust the front and rear speaker R6 (rear only) — F6 (front only)
(Fader)* balance
BAL Adjust the left and right speaker L6 (left only) — R6 (right only)
(Balance) balance
VOL Adjust the volume 00 (min.) — 50 (max.)
(Volume)
Note:
* If you are using a two-speaker system, set the fader level to “00.”
2
Adjust the level.
Note:
Normally the control dial works as the volume control. So you do
not have to select “VOL” to adjust the volume level.
EN13-18.KD-SX650[J]/f 10/20/99, 2:56 PM13
