1-15
KD-SX8250/KD-SX780
Prior to performing the following procedure, remove
the top cover, the chassis unit and the top plate
assembly.
Remove the screw J attaching the loading gear
bracket. The loading gear (6) and (7) come off the
loading gear bracket.
Pull out the loading gear (5).
1.
2.
Removing the loading gear (5), (6) and
(7) (See Fig.31 and 32)
Fig.31
Fig.32
J
J
Loading gear bracket
Loading gear bracket
Loading gear (6)
Loading gear (5)
Loading gear (6)
Loading gear (5)
Loading gear (7)
Loading gear (3)
