3-3
KD-SX8250/KD-SX780
Item
Parts number
Parts name
Area
A
Parts list (General assembly)
Q'ty
Description
Block No.
M1MM
1
------------
CD MECHA
1
2
GE10043-001A
T
O
P CHASSIS
1
3
GE40135-001A
EARTH PLATE
1
4
GE30568-003A
HEAT SINK
1
5
GE30393-001A
BOTTOM COVER
1
6
FSMA3005-001
INSULATOR
1
7
QYSDST2604Z
SCREW
3
CHASSIS+CD MECHA
8
FSKZ4005-001
SCREW
2
CHASSIS+SIDE PANEL
9
QYSDST2604Z
SCREW
3
CHASSIS+REAR BKT
10
QYSDST2606Z
SCREW
2
CHASSIS+MAIN PWB
11
QYSDST2612Z
SCREW
2
SIDE PANEL+IC BKT
12
QYSDSF2006M
SCREW
2
F.CHASSIS+CONECTOR
13
GE10049-003A
FRONT CHASSIS
1
KD-SX780
GE10049-004A
FRONT CHASSIS
1
KD-SX8250
14
QYSPSPT2020Z
MINI SCREW
2
15
GE30381-001A
LI
GHT LENS
1
16
VKZ4777-001
MINI SCREW
1
L.LENS+F.CHASSIS
17
GE30378-001A
OPEN LEVER
1
18
FSKS3015-001
LOCK LEVER(O
.
L)
1
19
VKS3798-002
RELEASE LEVER
1
20
GE30379-001A
LOCK LEVER(TOP)
1
21
VKS3794-003
LOCK LEVER(L)
1
22
VKS3795-002
LOCK LEVER(R)
1
23
VKS5563-001
GEAR
1
24
VKZ4786-002
OIL DAMPER
1
25
FSKW4012-001
T.SPRING
1
FOR L.LEVER(TOP)
26
GE40144-001A
T.SPRING
1
FOR R
ELEASE LEVER
27
VKW5262-001
T.SPRING
1
FOR L.LEVER(R)
28
QYSDSF2006M
SCREW
1
DAMPER+L.LEVER(R)
29
VKW5263-002
T.SPRING
1
FOR L.LEVER(L)
30
VKZ4777-001
MINI SCREW
1
LOCK LEVER(O
.L.)
31
FSKW4013-002
T.SPRING
1
FOR OPE
N
LEVER
32
GE40140-001A
BLIND
1
33
GE10041-001A
FRONT PANEL
1
KD-SX780
GE10041-002A
FRONT PANEL
1
KD-SX8250
34
GE30369-003A
FINDER LENS
1
KD-SX780
GE30369-002A
FINDER ASSY
1
KD-SX8250
35
GE40102-001A
REMOTE LENS
1
FOR RE
M
OTE
CON.
36
GE20104-001B
PRESET BUTTON
1
KD-SX8250
GE20104-002A
PRESET BUTTON
1
KD-SX780
37
GE30535-001A
POWER BUTTON
1
38
FSYH4036-074
SHEET
1
FOR NAV
BUTTON
39
GE30374-001A
SND FUNC BUTTON
1
40
GE30370-001A
D FUNC BUTTON
1
F/A,CD-CH
41
GE30371-001A
NAVIGATION
BUTTON
1
42
GE30372-001A
VOL KNOB
1
43
GE40127-001A
KNOB SPRING
1
44
GE40129-001A
SEL BUTTON
1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
50
52
Table of Contents
Safety Precaution
2
Preventing Static Electricity
3
Handling the Traverse Unit (Optical Pickup)
3
Disassembly Method
4
Removing the Front Chassis
4
Removing the Top Cover
7
Removing the Connector Board
7
Removing the Pickup Unit
10
Adjustment Method
18
Flow of Functional Operation Unit TOC Read
19
Feed Section
20
Maintenance of Laser Pickup
21
Replacement of Laser Pickup
21
Description of Major Ics
22
Terminal Layout
30
Block Diagram
36
Standard Schematic Diagrams
45
Printed Circuit Boards
48
Parts List
49
Exploded View of General Assembly and Parts List
50
CD Mechanism Assembly and Parts List
53
Packing Materials and Accessories Parts List
62
