KD-SX8250/KD-SX780
3-4
Item
Parts number Parts name Area
A
Q'ty
Description
45 GE30373-001A
RIM LENS
1
46 GE20123-001A
RIM COVER
1
47 GE40128-001A
EJECT BUTTON
1
48 VKW3001-330
COMP.SPRING
1
FOR EJECT BUTTON
49 GE30116-001A
DETACH BUTTON
1
50 VKW3001-330
COMP.SPRING
1
FOR DETACH BUTTON
51 GE10042-001A
REAR COVER
1
KD-SX780
GE10042-002A
REAR COVER
1
KD-SX8250
52 FSYH4036-078
SHEET
1
REAR COVER
53 VKZ4777-001
MINI SCREW
3
FRONT+REAR
54 VKZ4777-001
MINI SCREW
1
RIM COVER
55 GE30355-002A
NAME PLATE
1
KD-SX8250
GE30357-001A
NAME PLATE
1
KD-SX780
56 QAM0154-001
SUB-CABLE
1
KD-SX8250
57 VYTA500-001
PIN CAP
2
KD-SX8250
58 QLD0217-001
LCD MODULE
1
LCD1
59 QNZ0449-001
RUBBER CONNE
1
60 QNZ0450-001
RUBBER CONNE
1
61 GE30375-001A
LCD CASE
1
62 FSJK3028-001
LCD LENS
1
63 FSYH4061-001
LIGHTNG SHEET
1
64 FSKS3013-001
LENS CASE
1
65 GE40136-001A
IC BRACKET
1
66 GE40124-001A
REG BRACKET
1
67 FSKS3017-002
LED HOLDER
1
68 GE30382-003A
REAR BRACKET
1
69 QYSDST2606Z
SCREW
1
REAR BKT+REG BKT
70 QYSDST2606Z
SCREW
1
REAR BKT+ANT JACK
71 QYSDST2606Z
SCREW
1
REAR BKT+CD IN JACK
72 QYSDST2606Z
SCREW
2
REAR BKT+16P CONNECTO
73 QYSDSF3006Z
SCREW
1
REAR BKT+PIN JACK
74 QMFZ047-150-T
FUSE
A
1
F1
75 FSYH4036-069
SHEET
4
Parts list (General assembly)
Block No. M1MM
