KD-SX8250/KD-SX780

3-8

Item

Parts number Parts name Ar

Electrical parts list (Main board)

Remarks

Block No. 01

Item

Parts number Parts name Ar

Remarks

BZ871 QAN0002-001Z BUZZER

C 1 NCB31EK-473X C CAPACITOR

C 2 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 4 QERF1AM-227Z E CAPACITOR 220MF 20% 10V

C 5 NCB31HK-103X C CAPACITOR

C 6 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V

C 7 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 8 QERF1AM-227Z E CAPACITOR 220MF 20% 10V

C 9 NEA61AM-227X E CAPACITOR

C 10 NEA61AM-227X E CAPACITOR

C 11 NCS31HJ-331X C CAPACITOR

C 12 NCB31AK-224X C CAPACITOR

C 16 NDC31HJ-7R0X C CAPACITOR

C 17 NCS31HJ-121X C CAPACITOR

C 21 QERF1AM-107Z E CAPACITOR 100MF 20% 10V

C 22 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 23 NCB31EK-473X C CAPACITOR

C 24 NCB31EK-473X C CAPACITOR

C 25 NCB31EK-473X C CAPACITOR

C 26 QERF1CM-106Z E CAPACITOR 10MF 20% 16V

C 27 NCS31HJ-100X C CAPACITOR

C 28 NDC31HJ-7R0X C CAPACITOR

C 29 NCS31HJ-100X C CAPACITOR

C 30 NCS31HJ-101X C CAPACITOR

C 31 NCB31HK-102X C CAPACITOR

C 32 NCB31HK-103X C CAPACITOR

C 33 NCB31HK-103X C CAPACITOR

C 34 NCB31HK-103X C CAPACITOR

C 35 QFV61HJ-473Z MF CAPACITOR .047MF 5% 50V

C 36 NCB31HK-103X C CAPACITOR

C 37 NCB31HK-272X C CAPACITOR

C 38 NCB31HK-102X C CAPACITOR

C 39 NCB31HK-102X C CAPACITOR

C 40 NDC31HJ-470X C CAPACITOR

C 41 NCS31HJ-101X C CAPACITOR

C 103 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 105 NCB31EK-333X C CAPACITOR

C 203 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 205 NCB31EK-333X C CAPACITOR

C 251 QERF1CM-106Z E CAPACITOR KD-SX8250

C 252 NCB31EK-473X C CAPACITOR KD-SX8250

C 253 NCB31HK-103X C CAPACITOR KD-SX8250

C 254 QERF0JM-476Z E CAPACITOR KD-SX8250

C 255 NCB31HK-682X C CAPACITOR KD-SX8250

C 257 QERF1CM-106Z E CAPACITOR KD-SX8250

C 258 NCB31HK-103X C CAPACITOR KD-SX8250

C 259 QERF1CM-106Z E CAPACITOR KD-SX8250

C 260 QERF1AM-476Z E CAPACITOR KD-SX8250

C 261 QERF1CM-226Z E CAPACITOR KD-SX8250

C 301 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V

C 302 QERF1CM-106Z E CAPACITOR 10MF 20% 16V

C 303 QERF0JM-226Z E CAPACITOR 22MF 20% 6.3V

C 304 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 305 NCB31HK-102X C CAPACITOR

C 306 NCB31AK-334X C CAPACITOR

C 307 NCB31CK-104X C CAPACITOR

C 308 NCB31CK-104X C CAPACITOR

C 309 NCB31HK-102X C CAPACITOR

C 310 NCB31HK-102X C CAPACITOR

C 311 QERF1CM-106Z E CAPACITOR 10MF 20% 16V

C 312 NCB31AK-224X C CAPACITOR

C 313 NCB31EK-333X C CAPACITOR

C 322 QERF1AM-107Z E CAPACITOR 100MF 20% 10V

C 323 QERF1CM-226Z E CAPACITOR 22MF 20% 16V

C 331 QERF1HM-225Z E CAPACITOR KD-SX8250

C 332 QERF1HM-225Z E CAPACITOR KD-SX8250

C 341 QERF1AM-107Z E CAPACITOR KD-SX8250

C 342 QERF1EM-475Z E CAPACITOR KD-SX8250

C 343 QERF1AM-107Z E CAPACITOR KD-SX8250

C 344 QERF1EM-475Z E CAPACITOR KD-SX8250

C 345 QERF1CM-476Z E CAPACITOR KD-SX8250

C 346 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 347 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 348 QERF1AM-107Z E CAPACITOR KD-SX8250

C 351 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 352 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 353 NCS31HJ-391X C CAPACITOR

C 354 NCS31HJ-391X C CAPACITOR

C 355 QERF1CM-107Z E CAPACITOR 100MF 20% 16V

C 356 NCB31HK-223X C CAPACITOR

C 357 NCB31HK-223X C CAPACITOR

C 358 QERF1CM-476Z E CAPACITOR 47MF 20% 16V

C 359 QERF1CM-226Z E CAPACITOR 22MF 20% 16V

C 361 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V

C 362 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V

C 364 QERF1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 365 QERF1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 401 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V

C 402 QERF1CM-106Z E CAPACITOR 10MF 20% 16V

C 403 QERF0JM-226Z E CAPACITOR 22MF 20% 6.3V

C 404 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 405 NCB31HK-102X C CAPACITOR

C 406 NCB31AK-334X C CAPACITOR

C 407 NCB31CK-104X C CAPACITOR

C 408 NCB31CK-104X C CAPACITOR

C 409 NCB31HK-102X C CAPACITOR

C 410 NCB31HK-102X C CAPACITOR

C 411 QERF1CM-106Z E CAPACITOR 10MF 20% 16V

C 431 QERF1HM-225Z E CAPACITOR KD-SX8250

C 432 QERF1HM-225Z E CAPACITOR KD-SX8250

C 441 QERF1AM-107Z E CAPACITOR KD-SX8250

C 442 QERF1EM-475Z E CAPACITOR KD-SX8250

C 443 QERF1AM-107Z E CAPACITOR KD-SX8250

C 444 QERF1EM-475Z E CAPACITOR KD-SX8250

C 445 QERF1CM-476Z E CAPACITOR KD-SX8250

C 446 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 447 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 451 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 452 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 453 NCS31HJ-391X C CAPACITOR

C 454 NCS31HJ-391X C CAPACITOR

C 501 NCB31HK-103X C CAPACITOR

C 502 NCB31HK-103X C CAPACITOR

C 503 QERF1AM-107Z E CAPACITOR 100MF 20% 10V

C 504 NCB31HK-103X C CAPACITOR

C 505 QERF1AM-107Z E CAPACITOR 100MF 20% 10V

C 507 NCB31HK-682X C CAPACITOR

C 508 NCB31HK-103X C CAPACITOR

C 509 QERF1AM-107Z E CAPACITOR 100MF 20% 10V

C 510 NCB31CK-104X C CAPACITOR

C 511 NCB31CK-104X C CAPACITOR

C 512 NDC31HJ-820X C CAPACITOR

C 513 NCB31HK-103X C CAPACITOR

C 514 NDC31HJ-5R0X C CAPACITOR

C 521 NCB31HK-103X C CAPACITOR

C 522 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
