KD-SX8250/KD-SX780
Item
Parts number Parts name Ar
a
Remarks
A
C 523 NDC31HJ-470X C CAPACITOR
C 524 NCB31HK-153X C CAPACITOR
C 525 NCB31HK-103X C CAPACITOR
C 526 NCB31HK-272X C CAPACITOR
C 527 NCB31HK-103X C CAPACITOR
C 528 NCB31EK-333X C CAPACITOR
C 529 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 530 NCB31EK-333X C CAPACITOR
C 531 NCB31EK-473X C CAPACITOR
C 533 NCS31HJ-471X C CAPACITOR
C 534 NCS31HJ-471X C CAPACITOR
C 535 NCB31EK-473X C CAPACITOR
C 536 NCB31EK-473X C CAPACITOR
C 537 NCB31EK-473X C CAPACITOR
C 538 NCB31EK-473X C CAPACITOR
C 539 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 540 NCB31HK-103X C CAPACITOR
C 541 NCB31HK-103X C CAPACITOR
C 544 NCB31HK-103X C CAPACITOR
C 545 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 546 NCS31HJ-101X C CAPACITOR
C 547 NCB31CK-104X C CAPACITOR
C 548 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 549 NCB31HK-103X C CAPACITOR
C 550 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 551 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 552 NCB31HK-103X C CAPACITOR
C 553 NDC31HJ-100X C CAPACITOR
C 554 NDC31HJ-100X C CAPACITOR
C 555 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 556 NCB31HK-103X C CAPACITOR
C 561 QEDJ1AM-476Z E CAPACITOR 47MF 20% 10V
C 562 NCB31HK-103X C CAPACITOR
C 563 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 564 NCB31EK-473X C CAPACITOR
C 565 NCB31EK-473X C CAPACITOR
C 566 NCB31EK-473X C CAPACITOR
C 567 NCB31EK-473X C CAPACITOR
C 581 NCS31HJ-821X C CAPACITOR
C 582 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 583 NCS31HJ-121X C CAPACITOR
C 584 NCS31HJ-821X C CAPACITOR
C 585 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 588 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 591 NCS31HJ-821X C CAPACITOR
C 592 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 593 NCS31HJ-121X C CAPACITOR
C 594 NCS31HJ-821X C CAPACITOR
C 595 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 596 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 597 NCS31EJ-102X C CAPACITOR
C 598 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 698 NCB31AK-474X C CAPACITOR
C 699 NCB31EK-104X C CAPACITOR
C 702 NCB31EK-104X C CAPACITOR
C 703 NCB31EK-104X C CAPACITOR
C 708 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 709 NCB31EK-473X C CAPACITOR
C 710 NCB31EK-104X C CAPACITOR
C 711 NCB31EK-473X C CAPACITOR
C 712 NCB31EK-103X C CAPACITOR
C 713 NCB31EK-473X C CAPACITOR
C 714 NCB31EK-103X C CAPACITOR
C 715 NCS31HJ-101X C CAPACITOR
C 721 NDC31HJ-8R0X C CAPACITOR
C 722 NCS31HJ-270X C CAPACITOR
C 723 NCS31HJ-270X C CAPACITOR
C 724 NCS31HJ-220X C CAPACITOR
C 725 NCB31EK-103X C CAPACITOR
C 726 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 771 NCB31EK-473X C CAPACITOR
C 772 NCB31HK-103X C CAPACITOR
C 872 QERF1HM-104Z E CAPACITOR .10MF 20% 50V
C 873 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 914 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 951 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 952 NCB31EK-473X C CAPACITOR
C 953 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 954 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V
C 960 QEZ0518-228 E CAPACITOR 2200MF
C 961 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 962 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 963 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 964 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 965 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 966 NCB31AK-474X C CAPACITOR
C 967 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 968 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 969 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 970 NCB31EK-104X C CAPACITOR
C 971 QERF1CM-226Z E CAPACITOR KD-SX8250
C 975 NCB31EK-103X C CAPACITOR
C 976 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 977 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 981 NCB31CK-104X C CAPACITOR
C 982 NCB31CK-104X C CAPACITOR
C 983 NCB31CK-104X C CAPACITOR
C 984 NCB31CK-104X C CAPACITOR
C 991 NCS31HJ-101X C CAPACITOR
C 992 NCS31HJ-101X C CAPACITOR
C 993 NCS31HJ-101X C CAPACITOR
C 994 NCS31HJ-101X C CAPACITOR
C 995 NCS31HJ-101X C CAPACITOR
C 996 NCS31HJ-101X C CAPACITOR
C 997 NCS31HJ-101X C CAPACITOR
C 998 NCS31HJ-101X C CAPACITOR
CN251 QGA2006C1-04 CONNECTOR KD-SX8250
CN501 QGB2027M4-22S CONNECTOR
CN701 QNZ0007-002 CAR CONNECTOR
CN901 QNZ0002-001 JACK UNIT
D 1 1SS133-T1 SI DIODE
D 2 1SS133-T1 SI DIODE
D 3 1SS355-X DIODE
D 4 1SS355-X DIODE
D 251 1SS355-X DIODE KD-SX8250
D 252 1SS355-X DIODE KD-SX8250
D 253 1SS355-X DIODE KD-SX8250
D 254 1SS355-X DIODE KD-SX8250
D 255 1SS355-X DIODE KD-SX8250
D 256 1SS355-X DIODE KD-SX8250
D 301 1SS355-X DIODE
D 302 1SS355-X DIODE
D 324 UDZS10B-X Z DIODE
D 351 1SS133-T1 SI DIODE
D 371 1SS355-X DIODE
D 372 1SS355-X DIODE
