Item
Parts number Parts name Ar
a
Remarks
A
D 471 1SS355-X DIODE
D 472 1SS355-X DIODE
D 561 DSK10C-T1 DIODE
D 701 UDZS6.2B-X SI DIODE
D 702 UDZS6.2B-X SI DIODE
D 703 UDZS6.2B-X SI DIODE
D 704 UDZS5.6B-X Z DIODE
D 705 UDZS5.6B-X Z DIODE
D 706 UDZS5.6B-X Z DIODE
D 707 UDZS5.6B-X Z DIODE
D 708 UDZS5.6B-X Z DIODE
D 709 UDZS5.6B-X Z DIODE
D 711 SLR-56MC3F LED
D 714 UDZS5.1B-X Z DIODE
D 715 UDZS5.1B-X Z DIODE
D 716 UDZS5.1B-X Z DIODE
D 717 UDZS5.1B-X Z DIODE
D 721 1SS355-X DIODE
D 722 UDZS5.6B-X Z DIODE
D 893 1SS355-X DIODE
D 951 1SS133-T1 SI DIODE
D 952 1SS133-T1 SI DIODE
D 960 1N5401-TU-15 DIODE
D 961 1SS355-X DIODE
D 962 CRS03-W SB DIODE
D 963 CRS03-W SB DIODE
D 976 1SS133-T1 SI DIODE
D 977 UDZ11B-X Z DIODE
IC 21 TB2118F-X IC
IC251 NJM4565M-WE IC KD-SX8250
IC252 LC75344M-X IC KD-SX8250
IC301 LC75412W IC
IC341 BA3220FV-X IC KD-SX8250
IC351 LA47503 IC
IC441 BA3220FV-X IC KD-SX8250
IC501 TA2157FN-X IC
IC521 TC94A14FA IC
IC561 LA6579H-X IC
IC571 NJM4565M-WE IC
IC701 UPD784214AGC143 IC
IC702 IC-PST600M/G/-W IC
IC771 HD74HC126FP-X IC
IC961 HA13164A IC
J 1 QNB0100-002 ANT TERMINAL
J 771 QNZ0095-001 CONNECTOR
J 931 QNN0490-001 PIN JACK KD-SX8250
J 931 QNN0489-001 PIN JACK KD-SX780
L 1 QQL244J-4R7Z INDUCTOR
L 521 QQL244J-4R7Z INDUCTOR
L 522 QQL244J-4R7Z INDUCTOR
L 523 QQL244J-470Z INDUCTOR
L 524 QQL244J-4R7Z INDUCTOR
L 701 QQL244J-4R7Z INDUCTOR
L 702 NQL114M-4R7X INDUCTOR
L 961 QQR0703-001 CHOKE COIL
2 UN2211-X TRANSISTOR
3 UN2111-X TRANSISTOR
4 2SD601A/R/-X TRANSISTOR
5 2SB709A/R/-X TRANSISTOR
6 2SB815/7/-X TRANSISTOR
8 UN2211-X TRANSISTOR
31 UN2211-X TRANSISTOR
251 2SD1048/6-7/-X TRANSISTOR KD-SX8250
351 UN2211-X TRANSISTOR
371 2SD1048/6-7/-X TRANSISTOR
372 2SD1048/6-7/-X TRANSISTOR
471 2SD1048/6-7/-X TRANSISTOR
472 2SD1048/6-7/-X TRANSISTOR
501 2SB1241/QR/-T TRANSISTOR
521 UN2111-X TRANSISTOR
522 UN2211-X TRANSISTOR
561 2SB1322/RS/-T TRANSISTOR
871 UN2211-X TRANSISTOR
951 2SD601A/R/-X TRANSISTOR
963 2SB709A/R/-X TRANSISTOR
964 UN2211-X TRANSISTOR
971 UN2211-X TRANSISTOR KD-SX8250
976 UN2111-X TRANSISTOR
977 UN2111-X TRANSISTOR
R 1 NRSA63J-0R0X MG RESISTOR
R 2 NRSA63J-223X MG RESISTOR
R 3 NRSA63J-472X MG RESISTOR
R 4 NRSA63J-473X MG RESISTOR
R 5 NRSA02J-332X MG RESISTOR
R 6 NRS181J-6R8X MG RESISTOR
R 7 NRSA63J-473X MG RESISTOR
R 8 NRSA63J-472X MG RESISTOR
R 9 NRSA63J-473X MG RESISTOR
R 11 NRSA02J-0R0X MG RESISTOR
R 12 NRS181J-220X MG RESISTOR
R 13 NRS181J-6R8X MG RESISTOR
R 14 NRS181J-6R8X MG RESISTOR
R 15 NRSA63J-103X MG RESISTOR
R 21 NRS181J-100X MG RESISTOR
R 22 NRSA63J-622X MG RESISTOR
R 23 NRSA63J-222X MG RESISTOR
R 24 NRSA63J-222X MG RESISTOR
R 25 NRSA63J-222X MG RESISTOR
R 26 NRS181J-100X MG RESISTOR
R 27 NRSA63J-393X MG RESISTOR
R 28 NRSA63J-103X MG RESISTOR
R 29 NRSA63J-101X MG RESISTOR
R 30 NRSA63J-0R0X MG RESISTOR
R 31 NRSA63J-222X MG RESISTOR
R 32 NRSA63J-103X MG RESISTOR
R 33 NRSA63J-471X MG RESISTOR
R 34 NRSA63J-221X MG RESISTOR
R 101 NRSA63J-272X MG RESISTOR
R 102 NRSA63J-332X MG RESISTOR
R 201 NRSA63J-272X MG RESISTOR
R 202 NRSA63J-332X MG RESISTOR
R 251 NRSA63J-224X MG RESISTOR KD-SX8250
R 252 NRSA63J-224X MG RESISTOR KD-SX8250
R 253 NRSA63J-224X MG RESISTOR KD-SX8250
R 254 NRSA63J-224X MG RESISTOR KD-SX8250
R 255 NRSA63J-474X MG RESISTOR KD-SX8250
R 256 NRSA63J-104X MG RESISTOR KD-SX8250
R 257 NRSA63J-473X MG RESISTOR KD-SX8250
R 258 NRSA63J-104X MG RESISTOR KD-SX8250
R 259 NRSA63J-0R0X MG RESISTOR KD-SX8250
R 263 NRSA63J-104X MG RESISTOR KD-SX8250
R 264 NRSA63J-103X MG RESISTOR KD-SX8250
R 265 NRSA63J-223X MG RESISTOR KD-SX8250
R 266 NRSA63J-821X MG RESISTOR KD-SX8250
R 267 NRSA63J-222X MG RESISTOR KD-SX8250
R 268 NRSA63J-181X MG RESISTOR KD-SX8250
