KD-SX8250/KD-SX780
3-12
Item
Parts number Parts name Ar
a
Remarks
A
R 685 NRSA63J-105X MG RESISTOR
R 686 NRSA63J-105X MG RESISTOR
R 701 NRSA63J-472X MG RESISTOR
R 702 NRSA63J-472X MG RESISTOR
R 703 NRSA63J-472X MG RESISTOR
R 706 NRSA63J-222X MG RESISTOR
R 707 NRSA63J-222X MG RESISTOR
R 708 NRSA63J-0R0X MG RESISTOR
R 709 NRSA63J-222X MG RESISTOR
R 710 NRSA63J-473X MG RESISTOR
R 713 NRSA63J-473X MG RESISTOR
R 714 NRSA63J-103X MG RESISTOR
R 715 NRSA63J-103X MG RESISTOR
R 716 NRSA63J-0R0X MG RESISTOR
R 717 NRSA63J-103X MG RESISTOR
R 718 NRSA63J-472X MG RESISTOR
R 719 NRSA63J-103X MG RESISTOR
R 720 NRSA63J-472X MG RESISTOR
R 721 NRSA63J-103X MG RESISTOR
R 722 NRSA63J-472X MG RESISTOR
R 723 NRSA63J-473X MG RESISTOR
R 724 NRSA63J-103X MG RESISTOR
R 725 NRSA63J-103X MG RESISTOR
R 726 NRSA63J-222X MG RESISTOR
R 727 NRSA63J-103X MG RESISTOR
R 728 NRSA63J-106X MG RESISTOR
R 729 NRSA63J-222X MG RESISTOR
R 730 NRSA63J-821X MG RESISTOR
R 731 NRSA63J-222X MG RESISTOR
R 732 NRSA63J-222X MG RESISTOR
R 733 NRSA63J-473X MG RESISTOR
R 734 NRSA63J-473X MG RESISTOR
R 735 NRSA63J-103X MG RESISTOR
R 736 NRSA63J-0R0X MG RESISTOR
R 737 NRSA63J-0R0X MG RESISTOR
R 738 NRSA63J-0R0X MG RESISTOR
R 739 NRSA63J-0R0X MG RESISTOR
R 740 NRSA63J-0R0X MG RESISTOR
R 741 NRSA63J-0R0X MG RESISTOR
R 742 NRSA63J-0R0X MG RESISTOR
R 743 NRSA63J-473X MG RESISTOR
R 744 NRSA63J-0R0X MG RESISTOR
R 745 NRSA63J-0R0X MG RESISTOR
R 746 NRSA63J-103X MG RESISTOR
R 747 NRSA63J-472X MG RESISTOR
R 748 NRSA63J-222X MG RESISTOR
R 749 NRSA63J-0R0X MG RESISTOR
R 750 NRSA63J-122X MG RESISTOR
R 751 NRSA63J-103X MG RESISTOR
R 752 NRSA63J-103X MG RESISTOR
R 753 NRSA63J-473X MG RESISTOR
R 754 NRSA63J-102X MG RESISTOR
R 755 NRSA63J-122X MG RESISTOR
R 756 NRSA63J-472X MG RESISTOR
R 757 NRSA63J-102X MG RESISTOR
R 758 NRSA63J-103X MG RESISTOR
R 759 NRSA63J-473X MG RESISTOR
R 760 NRSA63J-103X MG RESISTOR
R 762 NRSA63J-103X MG RESISTOR
R 763 NRSA63J-103X MG RESISTOR
R 764 NRSA63J-473X MG RESISTOR
R 765 NRSA63J-473X MG RESISTOR KD-SX780
R 766 NRSA63J-473X MG RESISTOR KD-SX8250
R 767 NRSA63J-473X MG RESISTOR
R 769 NRSA63J-101X MG RESISTOR
R 772 NRSA63J-473X MG RESISTOR
R 773 NRSA63J-223X MG RESISTOR
R 774 NRSA63J-101X MG RESISTOR
R 775 NRSA63J-103X MG RESISTOR
R 776 NRSA63J-104X MG RESISTOR
R 777 NRSA63J-223X MG RESISTOR
R 778 NRSA63J-101X MG RESISTOR
R 779 NRSA63J-473X MG RESISTOR
R 781 NRSA63J-331X MG RESISTOR
R 782 NRSA63J-104X MG RESISTOR
R 791 NRS181J-511X MG RESISTOR
R 871 NRSA63J-222X MG RESISTOR
R 951 NRSA63J-473X MG RESISTOR
R 952 NRSA63J-123X MG RESISTOR
R 953 NRSA63J-184X MG RESISTOR
R 954 NRSA63J-223X MG RESISTOR
R 955 NRSA63J-101X MG RESISTOR
R 956 NRSA63J-102X MG RESISTOR
R 957 NRSA63J-563X MG RESISTOR
R 961 QRE142J-102X C RESISTOR 1.0K 5% 1/4W
R 962 NRSA02J-912X MG RESISTOR
R 963 NRSA02J-472X MG RESISTOR
R 966 NRSA63J-123X MG RESISTOR
R 967 NRSA63J-273X MG RESISTOR
R 968 NRS181J-222X MG RESISTOR
R 969 NRS181J-222X MG RESISTOR
R 971 NRSA63J-472X MG RESISTOR KD-SX8250
R 972 NRSA63J-473X MG RESISTOR KD-SX8250
S 701 QSW0451-001 DETECT SWITCH DETACH
S 702 QSW0451-001 DETECT SWITCH OPEN
S 703 QSW0534-001 TACT SW RESET
TU 1 QAU0258-001 TUNER
X 21 QAX0616-001Z CRYSTAL
X 521 QAX0413-001Z CRYSTAL
X 701 QAX0617-001Z CRYSTAL
X 702 QAX0401-001 CRYSTAL
Electrical parts list (Main board)
