3-13
KD-SX8250/KD-SX780
Item
Parts number Parts name Ar
a
Remarks
A
C 601 NBE20JM-475X TS E CAPACITOR
C 602 NCB31HK-103X C CAPACITOR
C 603 NCS31HJ-221X C CAPACITOR
C 604 NCB31AK-224X C CAPACITOR
C 605 NCB31AK-224X C CAPACITOR
C 607 NCB31EK-473X C CAPACITOR
C 608 NCB31HK-103X C CAPACITOR
C 609 NCB31HK-103X C CAPACITOR
CN601 QNZ0006-001 CAR CONNECTOR
D 601 SML-310LT/MN/-X LED
D 602 SML-310VT/JK/-X LED
D 603 SML-310VT/JK/-X LED
D 604 SML-310VT/JK/-X LED
D 605 SML-310VT/JK/-X LED
D 606 SML-310VT/JK/-X LED
D 607 SML-310VT/JK/-X LED
D 608 SML-310VT/JK/-X LED
D 609 SML-310VT/JK/-X LED
D 610 SML-310VT/JK/-X LED
D 611 SML-310VT/JK/-X LED
D 612 SML-310VT/JK/-X LED
D 613 SML-310VT/JK/-X LED
D 614 SML-310VT/JK/-X LED
D 615 SML-310VT/JK/-X LED
D 616 SML-310VT/JK/-X LED
D 617 LNJ308G81/1-3/X LED
D 618 SML-310VT/JK/-X LED
D 619 SML-310VT/JK/-X LED
D 620 SML-310VT/JK/-X LED
D 641 NSPW310BS/BRS/ LED
D 642 NSPW310BS/BRS/ LED
D 643 NSPW310BS/BRS/ LED
D 651 UDZS5.1B-X Z DIODE
D 652 1SS355-X DIODE
D 653 1SS355-X DIODE
D 654 1SS355-X DIODE
D 655 1SS355-X DIODE
D 656 1SS355-X DIODE
D 657 1SS355-X DIODE
D 658 1SS355-X DIODE
D 659 UDZS5.6B-X Z DIODE
EN601 QSW0976-001 ROTARY ENCODER
IC601 LC75873NW IC
IC602 RPM7138-V4 IR DETECT UNIT
J 601 QNS0201-001 3.5 JACK
641 2SB815/7/-X TRANSISTOR KD-SX8250
642 UN2211-X TRANSISTOR KD-SX8250
R 601 NRSA63J-821X MG RESISTOR
R 602 NRSA63J-821X MG RESISTOR
R 603 NRSA63J-122X MG RESISTOR
R 604 NRSA63J-182X MG RESISTOR
R 605 NRSA63J-821X MG RESISTOR
R 606 NRSA63J-821X MG RESISTOR
R 607 NRSA63J-122X MG RESISTOR
R 608 NRSA63J-182X MG RESISTOR
R 609 NRSA63J-272X MG RESISTOR
R 610 NRSA63J-392X MG RESISTOR
R 611 NRSA63J-821X MG RESISTOR
R 612 NRSA63J-821X MG RESISTOR
R 613 NRSA63J-122X MG RESISTOR
R 614 NRSA63J-182X MG RESISTOR
R 620 NRS181J-821X MG RESISTOR
R 621 NRSA02J-122X MG RESISTOR
R 622 NRSA02J-122X MG RESISTOR
R 623 NRSA02J-182X MG RESISTOR
R 624 NRSA02J-182X MG RESISTOR
R 625 NRSA02J-122X MG RESISTOR
R 626 NRSA02J-122X MG RESISTOR
R 627 NRSA02J-561X MG RESISTOR
R 628 NRSA02J-561X MG RESISTOR
R 629 NRSA02J-561X MG RESISTOR
R 630 NRSA02J-561X MG RESISTOR
R 631 NRSA02J-122X MG RESISTOR
R 632 NRSA02J-122X MG RESISTOR
R 633 NRSA02J-911X MG RESISTOR
R 634 NRSA02J-911X MG RESISTOR
R 635 NRSA02J-182X MG RESISTOR
R 636 NRSA02J-182X MG RESISTOR
R 637 NRSA02J-122X MG RESISTOR
R 638 NRSA02J-122X MG RESISTOR
R 639 NRSA02J-122X MG RESISTOR
R 640 NRSA02J-122X MG RESISTOR
R 641 NRS181J-431X MG RESISTOR
R 642 NRS181J-431X MG RESISTOR
R 643 NRS181J-431X MG RESISTOR
R 644 NRS181J-471X MG RESISTOR KD-SX8250
R 644 NRS181J-0R0X MG RESISTOR KD-SX780
R 645 NRSA63J-473X MG RESISTOR KD-SX8250
R 646 NRS181J-102X MG RESISTOR KD-SX8250
R 650 NRSA63J-0R0X MG RESISTOR
R 651 NRSA63J-473X MG RESISTOR
R 652 NRSA63J-473X MG RESISTOR
R 653 NRS181J-102X MG RESISTOR
R 654 NRSA63J-221X MG RESISTOR
R 655 NRSA63J-394X MG RESISTOR
R 656 NRSA63J-334X MG RESISTOR
R 657 NRSA63J-103X MG RESISTOR
R 658 NRSA63J-103X MG RESISTOR
R 659 NRSA63J-103X MG RESISTOR
R 660 NRSA63J-103X MG RESISTOR
R 661 NRSA63J-470X MG RESISTOR
R 662 NRSA63J-332X MG RESISTOR
R 663 NRSA63J-332X MG RESISTOR
R 664 NRSA63J-332X MG RESISTOR
R 666 NRSA63J-0R0X MG RESISTOR
R 667 NRSA63J-0R0X MG RESISTOR
R 670 NRSA63J-471X MG RESISTOR
S 601 NSW0124-001X TACT SW
S 602 NSW0124-001X TACT SW
S 603 NSW0124-001X TACT SW
S 604 NSW0124-001X TACT SW
S 605 NSW0124-001X TACT SW
S 606 NSW0124-001X TACT SW
S 607 NSW0124-001X TACT SW
S 608 NSW0124-001X TACT SW
S 609 NSW0124-001X TACT SW
S 610 NSW0124-001X TACT SW
S 611 NSW0124-001X TACT SW
S 612 NSW0124-001X TACT SW
S 613 NSW0124-001X TACT SW
S 614 NSW0124-001X TACT SW
S 615 NSW0124-001X TACT SW
S 616 NSW0124-001X TACT SW
S 617 NSW0124-001X TACT SW
Electrical parts list (Front board)
Block No. 02
Item
Parts number Parts name Ar
a
Remarks
