KD-SX991R/KD-SX911R
3-3
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No.
M1MM
1 --------------- CD MECHA 1
2 FSJC1029-404 TOP CHASSIS 1
3 FSMH3001-204 SIDE PANEL 1
4 FSKM3011-002 BOTTOM COVER 1
5 FSMA3005-001 INSULATOR 1
6 QYSDST2604Z SCREW 3 CHASSIS+CD MECHA
7 FSKZ4005-001 SCREW 2 CHASSIS+SIDE PANEL
8 QYSDST2604Z SCREW 3 CHASSIS+REAR BKT
9 QYSDST2606Z SCREW 2 CHASSIS+MAIN PWB
10 FSKZ4005-001 SCREW 1 SIDE PANEL+IC BKT
11 QYSDSF2006M SCREW 2 F.CHASSIS+CONNECTOR
12 FSJC1061-002 FRONT CHASSIS 1
13 VJK3709-002 LIGHT LENS 1
14 VKZ4777-001 MINI SCREW 1 L.LENS+F.CHASSIS
15 FSYH4036-057 SHEET 1
16 FSYH4036-055 SHEET 1 LIGHT LENS
17 FSKS3014-001 OPEN LEVER 1
18 FSKS3015-001 LOCK LEVER
(
O.L
)
1
19 VKS3798-002 RELEASE LEVER 1
20 VKS3793-001 LOCK LEVER
(
TOP
)
1
21 VKS3794-003 LOCK LEVER
(
L
)
1
22 VKS3795-002 LOCK LEVER
(
R
)
1
23 VKS5563-001 GEAR 1
24 VKZ4786-002 OIL DAMPER 1
25 FSKW4012-001 T.SPRING 1 FOR L.LEVER
(
TOP
)
26 VKW5264-005 T.SPRING 1 FOR RELEASE LEVER
27 VKW5262-001 T.SPRING 1 FOR L.LEVER
(
R
)
28 QYSDSF2006M SCREW 1 DAMPER+L.LEVER
(
R
)
29 VKW5263-002 T.SPRING 1 FOR L.LEVER
(
L
)
30 VKZ4777-001 MINI SCREW 1 LOCK LEVER
(
O.L.
)
31 FSKW4013-002 T.SPRING 1 FOR OPEN LEVER
32 VYTA526-002 BLIND 1
33 GE10005-001A FRONT PANEL 1
34 GE30113-011A FINDER ASSY 1 KD-SX911R
GE30113-010A FINDER ASSY 1 KD-SX991R
35 FSJK4009-001 REMOTE LENS 1
36 GE20104-001B PRESET BUTTON 1 1-6
(
2 COLOUR
)
37 GE30105-002B POWER BUTTON 1
38 GE30106-001A SND FUNC BUTTON 1
39 GE20110-003C D.FUNC BUTTON 1
40 GE20103-001A PUSH BUTTON
(
3
)
1
41 GE20109-001C UP DOWN BUTTON 1
42 GE30103-001B KNOB 1
43 LV40833-001A SPACER 2
44 GE30102-002A SEL BUTTON 1
45 GE30104-001A RIM LENS 1
46 GE30115-002A EJECT BUTTON 1
47 VKW3001-330 COMP.SPRING 1 FOR EJECT BUTTON
RPT,RND,SCM
CD,F/A,CD-CH
