KD-SX991R/KD-XS911R
3-4
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
48 GE30116-001A DETACH BUTTON 1
49 VKW3001-330 COMP.SPRING 1 FOR DETACH BUTTON
50 GE10006-001A REAR COVER 1
51 FSYH4036-035 SHEET 1
52 VKZ4777-001 MINI SCREW 4 FRONT+REAR
53 QNZ0449-001 RUBBER CONNECTOR 1
54 QNZ0450-001 RUBBER CONNECTOR 1
55 GE30114-001A LCD CASE 1
56 FSJK3028-001 LCD LENS 1
57 FSYH4061-001 LIGHTNG SHEET 2 KD-SX991R
FSYH4061-001 LIGHTNG SHEET 1 KD-SX911R
58 FSYH4036-052 SHEET 1
59 FSKS3013-001 LENS CASE 1
60 GE30157-002A NAME PLATE 1 KD-SX991R
GE30156-002A NAME PLATE 1 KD-SX911R
61 LV41843-001A LASER CAUTION 1
62 FSKL4024-001 IC BRACKET 1
63 GE40103-001A REG BRACKET 1
64 GE40104-002B HEAT SINK 1
65 FSKM3012-014 REAR BRACKET 1
66 QYSDST2606Z SCREW 1 REAR BKT+REG BKT
67 QYSDST2606Z SCREW 1 REAR BKT+ANT JACK
68 QYSDST2606Z SCREW 1 REAR BKT+CD IN JACK
69 QYSDSF3006Z SCREW 1 REAR BKT+PIN JACK
70 QMFZ047-150-T FUSE
1
71 FSKS3017-002 LED HOLDER 1
72 VMA4652-001SS EARTH PLATE 1
73 FSYH4061-002 LIGHTNG SHEET 1 KD-SX911R
LCD 1 QLD0164-001 LCD MODULE 1 KD-SX911R
QLD0163-001 LCD MODULE 1 KD-SX991R
