KD-SX980
1-7
Removing the (LCD & key) control switch
board (See Fig.11 to 13)
Prior to performing the following procedure, remove
the front panel assembly.
Remove the four screws I attaching the rear cover
on the back of the front panel assembly.
Unjoint the nine joints i with the front panel and the
rear cover.
Remove the control switch board on the back of the
front panel.
1.
2.
3.
I
I
I
I
Fig. 11
Fig. 13
Fig. 12
LCD & Key control board
Joints i
Joints i
Joints i
Joints i
Front panel
Rear cover
