JVC KD-X262 User Manual

8
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
USB/iPod/ANDROID
Start playback
The source changes automatically and playback starts.
KD-X262/
KD-X161:
KD-X162:
*1 Do not leave the cable inside the car when not using.
*2 You can control Android device using the Android device itself via other media player
applications installed in the Android device.
Preparation:
You can listen to music from a portable audio player via the auxiliary input
jack.
• Select
[ON] for [BUILT-IN AUX] in [SOURCESELECT] . (Page 5)
Start listening
1
Connect a portable audio player (commercially available).
KD-X262/KD-X162:
3.5 mm stereo mini plug with “L” shaped connector
(commercially available)
Portable audio player
Auxiliary input jack
KD-X161:
Auxiliary input jack
3.5 mm stereo mini plug with “L” shaped connector
(commercially available)
Portable audio player
2 Press source button repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Use a 3-core plug head stereo mini plug for optimum audio
output.
AUX
USB input terminal
USB input terminal
USB 2.0 cable*1
(commercially available)
USB cable*1
(commercially available)
Accessory of the iPod/iPhone*1
USB
iPod/iPhone
ANDROID*2
JS_JVC_KD_X262_E_EN_3.indd 8JS_JVC_KD_X262_E_EN_3.indd 8 8/14/2018 11:35:07 AM8/14/2018 11:35:07 AM

JVC KD-X262 Specifications

General

DIN size	-
Output power	200 W
Product color	Black, Red
Ready for iPod	Yes
High pass filter	No
Audio output channels	- channels
Equalizer bands quantity	3
Maximum power per channel	50 W
Audio formats supported	FLAC, MP3, WAV, WMA
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	900 g

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
