JVC KD-X262 User Manual

12
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
[SUBWOOFER SET]*3 [ON]: Turns on the subwoofer output. ; [OFF]: Cancels.
[SUBWOOFER LPF]*1
[FRQ THROUGH]: All signals are sent to the subwoofer. ;
[FRQ55HZ]/[FRQ85HZ]/[FRQ120HZ]: Audio signals with frequencies
lower than 55 Hz/85 Hz/120 Hz are sent to the subwoofer.
[SUB.W PHASE]*1*4
[REVERSE] (180°)/[NORMAL] (0°): Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
[FADER]
[POSITIONR06] to [POSITIONF06] ([POSITION00]): Adjusts the front
and rear speaker output balance.
[BALANCE]*5
[POSITIONL06] to [POSITIONR06] ([POSITION00]): Adjusts the left
and right speaker output balance.
[VOLUME ADJUST]
[LEVEL–15] to [LEVEL+06] ([LEVEL 00]): Presets the initial volume
level of each source by comparing to the FM volume level. (Before
adjustment, select the source you want to adjust. “VOL ADJ FIX” appears
if FM is selected.)
[AMPGAIN]
[LOWPOWER]: Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50 W to prevent damaging
the speakers.) ; [HIGHPOWER]: The maximum volume level is 35.
[D.T.EXPANDER]
(Digital Track
Expander)
[ON]: Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression. ; [OFF]: Cancels.
[SPK/PREOUT] Depending on the speaker connection method, select the appropriate
setting for the desired output. (See “Speaker output settings”.)
*1 Displayed only when [SUBWOOFER SET] is set to [ON].
*2 Displayed only when [SPK/PREOUT] is set to [SUB.W/SUB.W].
*3 Displayed only when [SPK/PREOUT] is set to [REAR/SUB.W] or [SUB.W/SUB.W].
*4 Selectable only if a setting other than [FRQTHROUGH] is selected for [SUBWOOFERLPF].
*5 This adjustment will not affect the subwoofer output.
AUDIO SETTINGS
Speaker output settings [SPK/PRE OUT]
Select the output setting for the speakers [SPK/PRE OUT] , based on the speaker
connection method.
Connection via lineout terminals
For connections through an external amplifier. (Page 19)
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
[REAR/REAR] Rear speakers output
[REAR/SUB.W] (default) Subwoofer output
[SUB.W/SUB.W] Subwoofer output
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page 19)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W] Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[FRQ120HZ] is selected in [SUBWOOFERLPF] and [FRQTHROUGH] is not available.
–
[POSITION R01] is selected in [FADER] and selectable range is [POSITION R06] to
[POSITION 00] .
JS_JVC_KD_X262_E_EN_3.indd 12JS_JVC_KD_X262_E_EN_3.indd 12 8/14/2018 11:35:09 AM8/14/2018 11:35:09 AM

JVC KD-X262 Specifications

General

DIN size	-
Output power	200 W
Product color	Black, Red
Ready for iPod	Yes
High pass filter	No
Audio output channels	- channels
Equalizer bands quantity	3
Maximum power per channel	50 W
Audio formats supported	FLAC, MP3, WAV, WMA
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	900 g

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
