JVC KS-F185 Service Manual

3-11
Switch board
(F185_UH,UN,U) (F185S/F185G_UN)
Block No. [0][2]
R17 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R51 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R52 QRE141J-512Y C RESISTOR 5.1k
Ω 1/4W J
R61 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R62 QRE141J-512Y C RESISTOR 5.1k
Ω 1/4W J
R131 QRE141J-392Y C RESISTOR 3.9k
Ω 1/4W J
R132 QRE141J-752Y C RESISTOR 7.5k
Ω 1/4W J
R163 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R164 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R165 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R231 QRE141J-392Y C RESISTOR 3.9k
Ω 1/4W J
R232 QRE141J-752Y C RESISTOR 7.5k
Ω 1/4W J
R263 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R264 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R265 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R702 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R703 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R704 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R705 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R707 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R708 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R709 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R710 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R711 QRE141J-224Y C RESISTOR 220k
Ω 1/4W J
R712 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R713 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R714 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R715 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R718 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R719 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R720 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R721 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R722 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R724 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R725 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R726 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R727 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R728 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R771 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R772 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R773 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R774 QRE141J-152Y C RESISTOR 1.5k
Ω 1/4W J
R783 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R784 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R785 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R786 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R787 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R788 QRE141J-242Y C RESISTOR 2.4k
Ω 1/4W J
R789 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R790 QRE141J-474Y C RESISTOR 470k
Ω 1/4W J
R792 QRE141J-6R8Y C RESISTOR 6.8
Ω 1/4W J
R795 QRE141J-183Y C RESISTOR 18k
Ω 1/4W J
R796 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R797 QRE141J-123Y C RESISTOR 12k
Ω 1/4W J
R931 QRE141J-100Y C RESISTOR 10
Ω 1/4W J
R941 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R972 QRE141J-272Y C RESISTOR 2.7k
Ω 1/4W J
R973 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R985 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R990 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R991 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
R992 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
R993 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
R994 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
R996 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R997 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R998 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R999 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
L1 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L781 QQL231K-470Y INDUCTOR I/M 47uH K
L782 QQL231K-470Y INDUCTOR I/M 47uH K
L783 QQL231K-470Y INDUCTOR I/M 47uH K
L981 QQR1367-001 CHOKE COIL
CJ701 VMC0334-001 CONNECTOR
CJ921 QNN0519-001 PIN JACK
CN721 QGB1214J1-06S CONNECTOR B-B (1-6)
 Symbol No. Part No. Part Name Description Local
CN901 QGB1214J1-06S CONNECTOR B-B (1-6)
CP981 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
TU1 QAU0311-001 TUNER
X701 QAX0406-001Z CRYSTAL 4.500MHz
 Symbol No. Part No. Part Name Description Local
IC651 LC75823W IC
D601 SML-310LT/MN/-X LED
D602 LNJ308G81/1-3/X LED
D603 LNJ308G81/1-3/X LED
D604 LNJ308G81/1-3/X LED
D605 LNJ308G81/1-3/X LED
D606 LNJ308G81/1-3/X LED
D607 LNJ308G81/1-3/X LED
D608 LNJ308G81/1-3/X LED
D609 LNJ308G81/1-3/X LED
D610 LNJ308G81/1-3/X LED
D611 LNJ308G81/1-3/X LED
D612 LNJ308G81/1-3/X LED
D613 LNJ308G81/1-3/X LED
D614 LNJ308G81/1-3/X LED
D615 LNJ308G81/1-3/X LED
D616 LNJ308G81/1-3/X LED
D617 LNJ308G81/1-3/X LED
D618 LNJ308G81/1-3/X LED
D619 LNJ308G81/1-3/X LED
D654 UDZS5.1B-X Z DIODE
C651 NCB31CK-105X C CAPACITOR 1uF 16V K
C652 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C653 NCB31HK-681X C CAPACITOR 680pF 50V K
R601 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R602 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R603 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R604 NRSA63J-911X MG RESISTOR 910
Ω 1/16W J
R605 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R606 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R607 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R608 NRSA63J-911X MG RESISTOR 910
Ω 1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R610 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R611 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R612 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R613 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R614 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R615 NRSA63J-911X MG RESISTOR 910
Ω 1/16W J
R635 NRS181J-221X MG RESISTOR 220
Ω 1/8W J
R636 NRSA02J-122X MG RESISTOR 1.2k
Ω 1/10W J
R637 NRSA02J-122X MG RESISTOR 1.2k
Ω 1/10W J
R638 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R639 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R640 NRSA02J-431X MG RESISTOR 430
Ω 1/10W J
R642 NRSA02J-271X MG RESISTOR 270
Ω 1/10W J
R644 NRSA02J-271X MG RESISTOR 270
Ω 1/10W J
R646 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R647 NRSA02J-821X MG RESISTOR 820
Ω 1/10W J
R648 NRSA02J-431X MG RESISTOR 430
Ω 1/10W J
R650 NRSA02J-431X MG RESISTOR 430
Ω 1/10W J
R652 NRSA02J-122X MG RESISTOR 1.2k
Ω 1/10W J
R653 NRSA02J-122X MG RESISTOR 1.2k
Ω 1/10W J
R654 NRSA02J-152X MG RESISTOR 1.5k
Ω 1/10W J
R655 NRSA02J-473X MG RESISTOR 47k
Ω 1/10W J
R657 NRSA02J-184X MG RESISTOR 180k
Ω 1/10W J
R661 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R662 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
