JVC KS-F185 Service Manual

3-12
Mechanism control board
(F185_UH,UN,U) (F185S/F185G_UN)
Block No. [0][3]
Main board (F185_UH3,UN3,U3)
Block No. [0][4]
R663 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
CP701 VMC0335-001 PANEL CONNECTOR
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
IC901 UPC1228HA IC
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C103 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C104 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C105 QFV61HJ-103Z MF CAPACITOR 0.01uF 50V J
C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C202 QERF1HM-474Z E CAPACITOR 0.47uF 50V M
C203 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C204 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C205 QFV61HJ-103Z MF CAPACITOR 0.01uF 50V J
C901 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
R101 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
R103 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R104 QRE141J-334Y C RESISTOR 330k
Ω 1/4W J
R201 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
R203 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R204 QRE141J-334Y C RESISTOR 330k
Ω 1/4W J
R901 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
CJ901 QGA2002C1-05 CONNECTOR W-B (1-5)
CP721 QGB1214K1-06S CONNECTOR B-B (1-6)
CP722 QGA2002F1-06 CONNECTOR W-B (1-6)
CP901 QGB1214K1-06S CONNECTOR B-B (1-6)
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC701 UPD178078GF-708 IC
IC902 KIA7810API IC
IC911 TEA6320T-X IC
IC941 LA4743K POWER IC
IC961 AN80T05LF IC
Q2 UN2211-X TRANSISTOR
Q7 2SC3661-X TRANSISTOR
Q8 KRC101S-X TRANSISTOR
Q10 2SC3661-X TRANSISTOR
Q11 2SC2412K/R/-X TRANSISTOR
Q12 2SC2412K/R/-X TRANSISTOR
Q131 2SC2412K/R/-X TRANSISTOR
Q231 2SC2412K/R/-X TRANSISTOR
Q701 2SC2412K/R/-X TRANSISTOR
Q953 UN2211-X TRANSISTOR
Q959 UN2211-X TRANSISTOR
Q960 2SA1037AK/RS/-X TRANSISTOR
Q961 2SA1037AK/RS/-X TRANSISTOR
Q962 2SB1322/RS/-T TRANSISTOR
Q963 2SA1037AK/RS/-X TRANSISTOR
Q964 UN2211-X TRANSISTOR
Q965 UN2211-X TRANSISTOR
Q966 UN2211-X TRANSISTOR
Q967 2SA1037AK/RS/-X TRANSISTOR
Q978 UN2211-X TRANSISTOR
Q979 UN2111-X TRANSISTOR
Q981 UN2111-X TRANSISTOR
D1 1SS355-X SI DIODE
D2 1SS355-X SI DIODE
D6 UDZS9.1B-X Z DIODE
D30 1SS355-X SI DIODE
D744 NRS181J-0R0X MG RESISTOR 0
Ω 1/8W J
D751 UDZS6.2B-X Z DIODE
D752 UDZS6.2B-X Z DIODE
D753 UDZS6.2B-X Z DIODE
D754 UDZS6.2B-X Z DIODE
D755 UDZS6.2B-X Z DIODE
D756 UDZS6.2B-X Z DIODE
D757 UDZS6.2B-X Z DIODE
D776 1SS355-X SI DIODE
D931 1SS355-X SI DIODE
D932 1SS355-X SI DIODE
D961 1N5401-F64 DIODE
D963 1SS355-X SI DIODE
D964 1SS355-X SI DIODE
D965 RB160M-30-X SB DIODE
D966 RB160M-30-X SB DIODE
D977 1SS355-X SI DIODE
D978 UDZS11B-X Z DIODE
D982 1SS355-X SI DIODE
D984 1SS355-X SI DIODE
C1 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C2 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C3 QERF1AM-227Z E CAPACITOR 220uF 10V M
C4 QERF1AM-227Z E CAPACITOR 220uF 10V M
C6 NCB31EK-563X C CAPACITOR 0.056uF 25V K
C7 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C8 QERF1AM-107Z E CAPACITOR 100uF 10V M
C9 QERF1AM-227Z E CAPACITOR 220uF 10V M
C17 NCS31HJ-151X C CAPACITOR 150pF 50V J
C18 QERF1HM-474Z E CAPACITOR 0.47uF 50V M
C20 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C21 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C24 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C31 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C112 QERF1HM-105Z E CAPACITOR 1uF 50V M
C113 NCB31HK-822X C CAPACITOR 8200pF 50V K
C114 NCB21CK-104X C CAPACITOR 0.1uF 16V K
C115 QERF1HM-224Z E CAPACITOR 0.22uF 50V M
C116 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C117 NCB31EK-123X C CAPACITOR 0.012uF 25V K
