JVC KS-F350R

Arrangement of adjusting & test points
Head section view
Cassette mechanism
(Surface)
Tape speed adjust
Motor assembly
Playback head
Azimuth screw
Head azimuth screw
Fixed screw
Height adjusting screw c
Height adjusting screw b
Height adjusting screw a
Playback head
