JVC KS-F350R Service Manual

Item
Parts number
Parts name
Area
A
Electrical parts list
Remarks
Block No.
01
C 1
QERF1HM-104Z
E CAPACITOR
.10MF 20% 50V
C 6
NCB21EK-563X
C CAPACITOR
C 7
NCB21EK-123X
C CAPACITOR
C 9
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 17
NCS21HJ-151X
C CAPACITOR
C 18
QERF1HM-224Z
E CAPACITOR
.22MF 20% 50V
C 20
NCS21HJ-102X
C CAPACITOR
C 21
QEQF1HM-225Z
E CAPACITOR
2.2MF 20% 50V
C 24
NCB21EK-473X
C CAPACITOR
C 25
NCB21EK-104X
C CAPACITOR
C 30
NDC21HJ-470X
C CAPACITOR
C 101
NCS21HJ-821X
C CAPACITOR
C 102
QERF1HM-474Z
E CAPACITOR
.47MF 20% 50V
C 103
NCS21HJ-101X
C CAPACITOR
C 104
QERF0JM-476Z
E CAPACITOR
47MF 20% 6.3V
C 105
QFV61HJ-103Z
TF CAPACITOR
.010MF 5% 50V
C 111
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 112
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 113
QFLA1HJ-822Z
M CAPACITOR
8200PF 5% 50V
C 114
QFV61HJ-154Z
TF CAPACITOR
.15MF 5% 50V
C 115
QERF1HM-224Z
E CAPACITOR
.22MF 20% 50V
C 116
QFV61HJ-333Z
TF CAPACITOR
.033MF 5% 50V
C 117
QFLA1HJ-562Z
M CAPACITOR
5600PF 5% 50V
C 118
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 119
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 143
NCS21HJ-471X
C CAPACITOR
C 144
NCS21HJ-471X
C CAPACITOR
C 151
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 152
NCB21HK-122X
C CAPACITOR
C 153
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 154
NCB21HK-153X
C CAPACITOR
C 201
NCS21HJ-821X
C CAPACITOR
C 202
QERF1HM-474Z
E CAPACITOR
.47MF 20% 50V
C 203
NCS21HJ-101X
C CAPACITOR
C 204
QERF0JM-476Z
E CAPACITOR
47MF 20% 6.3V
C 205
QFV61HJ-103Z
TF CAPACITOR
.010MF 5% 50V
C 211
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 212
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 213
QFLA1HJ-822Z
M CAPACITOR
8200PF 5% 50V
C 214
QFV61HJ-154Z
TF CAPACITOR
.15MF 5% 50V
C 215
QERF1HM-224Z
E CAPACITOR
.22MF 20% 50V
C 216
QFV61HJ-333Z
TF CAPACITOR
.033MF 5% 50V
C 217
QFLA1HJ-562Z
M CAPACITOR
5600PF 5% 50V
C 218
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 219
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 243
NCS21HJ-471X
C CAPACITOR
C 244
NCS21HJ-471X
C CAPACITOR
C 251
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 252
NCB21HK-122X
C CAPACITOR
C 253
QER41HM-105
E CAPACITOR
1.0MF 20% 50V
C 254
NCB21HK-153X
C CAPACITOR
C 301
NCB21HK-331X
C.CAPA. C.M
SQ USE
C 302
NCB21HK-103X
C CAPACITOR
SQ USE
C 303
NCB21EK-472X
C CAPACITOR
MARKET CLAIM
C 304
NCB21EK-104X
C CAPACITOR
SQ USE
C 305
QERF1HM-225Z
E CAPACITOR
SQ USE
C 701
NDC21HJ-270X
C CAPACITOR
C 702
NDC21HJ-270X
C CAPACITOR
C 703
NCB21EK-104X
C CAPACITOR
C 704
NCB21EK-104X
C CAPACITOR
C 705
NCB21EK-103X
C CAPACITOR
C 707
NCB21EK-104X
C CAPACITOR
C 708
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 709
QERF0JM-107Z
E CAPACITOR
100MF 20% 6.3V
C 710
NCS21HJ-121X
C CAPACITOR
C 711
NCB21CK-224X
C CAPACITOR
C 712
NCB21HK-104X
C CAPACITOR
C 751
NCB21EK-104X
C CAPACITOR
KS-FX453R/FX450
C 761
NCB21EK-223X
C CAPACITOR
C 762
NCS21HJ-561X
C CAPACITOR
C 763
QERF1HM-225Z
E CAPACITOR
2.2MF 20% 50V
C 764
NDC21HJ-820X
C CAPACITOR
C 765
NDC21HJ-470X
C CAPACITOR
C 766
QER41CM-476
E CAPACITOR
47MF 20% 16V
C 767
NCB21HK-103X
C CAPACITOR
C 901
QER41AM-107
E CAPACITOR
100MF 20% 10V
C 911
QER41CM-476
E CAPACITOR
47MF 20% 16V
C 912
QERF1CM-107Z
E CAPACITOR
100MF 20% 16V
C 913
QERF1CM-107Z
E CAPACITOR
100MF 20% 16V
C 932
NCB21EK-104X
C CAPACITOR
C 941
NCB21EK-104X
C CAPACITOR
C 942
NCB21EK-104X
C CAPACITOR
C 943
NCB21EK-104X
C CAPACITOR
C 944
NCB21EK-104X
C CAPACITOR
C 945
QERF1EM-475Z
E CAPACITOR
4.7MF 20% 25V
C 961
QETM1CM-228
E CAPACITOR
2200MF 20% 16V
C 962
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 963
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 964
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 965
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 966
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 967
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 969
NCB21EK-473X
C CAPACITOR
C 970
NCB21EK-473X
C CAPACITOR
C 971
NCB21EK-104X
C CAPACITOR
C 977
QER41AM-227
E CAPACITOR
220MF 20% 10V
C 978
QERF1EM-475Z
E CAPACITOR
4.7MF 20% 25V
C 979
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 980
NCB21HK-473X
C CAPACITOR
C 981
QERF0JM-107Z
E CAPACITOR
100MF 20% 6.3V
C 982
QER41CM-106
E CAPACITOR
10MF 20% 16V
C 984
QER41AM-227
E CAPACITOR
220MF 20% 10V
CJ701
VMC0334-001
CONNECTOR
CJ901
QGA2002C1-05
CONNECTOR
CJ902
QGA2002F1-06
CONNECTOR
CN90
QGB1214J1-06S
CONNECTOR
CN90
QGB1214J1-06S
CONNECTOR
CP90
QGB1214K1-06S
CONNECTOR
CP90
QGB1214K1-06S
CONNECTOR
CP96
QNZ0112-001
CAR CONNECTOR
D 1
1SS119-041
SI DIODE
D 2
1SS119-041
SI DIODE
D 3
MA152WK-X
SI DIODE
D 5
1SS119-041
SI DIODE
D 6
MTZJ9.1C-T2
Z DIODE I/M
D 701
1SS119-041
SI DIODE
D 741
1SS119-041
SI DIODE
D 742
1SS119-041
SI DIODE
D 744
DSK10C-T1
DIODE
D 776
DSK10C-T1
DIODE
D 931
MA152WA-X
DIODE
D 951
1SS133-T2
SI DIODE IM
D 961
1N5401-TU-15
DIODE
D 963
MA152WA-X
DIODE
D 965
DSK10C-T1
DIODE
D 966
DSK10C-T1
DIODE
D 977
MA152WK-X
SI DIODE
D 978
MTZJ11B-T2
ZENER DIODE
D 980
MA152WA-X
DIODE
D 981
MA152WA-X
DIODE
D 982
MA152WK-X
SI DIODE
IC701
UPD178016AGC5
IC
IC751
HD74HC126FP-X
IC
IC761
SAA6579T-X
IC
Item
Parts number
Parts name
A
Remarks
Area
KS-FX453R/FX450R
R
(Main board)
