JVC KS-F350R Service Manual

Item
Parts number
Parts name
Area
A
Electrical parts list
Remarks
Block No.
01
IC901
UPC1228HA
IC
IC911
TEA6320T-X
IC
IC941
HA13158A
IC
IC961
AN80T05LF
IC
J 1
QNZ0009-001
CAR ANT JACK
J 751
QNZ0095-001
CONNECTOR
KS-FX453R/FX450
J 931
QNN0183-001
PIN JACK
L 1
QQL231K-4R7Y
INDUCTOR
L 701
QQL231K-470Y
INDUCTOR
L 961
QQR0528-002
CHOKE COIL
Q 1
DTC114EKA-X
TRANSISTOR
Q 2
DTC114EKA-X
TRANSISTOR
Q 3
2SC2412K/R/-X
TRANSISTOR
Q 4
DTA114EKA-X
DIGITAL.TRANSIS
Q 5
2SA1037AK/RS/-X
TRANSISTOR
Q 6
2SA1037AK/RS/-X
TRANSISTOR
Q 7
2SC3661-X
TRANSISTOR
Q 10
2SC3661-X
TRANSISTOR
Q 11
2SC2412K/R/-X
TRANSISTOR
Q 12
2SC2412K/R/-X
TRANSISTOR
Q 131
2SC2412K/R/-X
TRANSISTOR
Q 151
2SC2412K/R/-X
TRANSISTOR
Q 231
2SC2412K/R/-X
TRANSISTOR
Q 251
2SC2412K/R/-X
TRANSISTOR
Q 301
2SD601A/R/-X
TRANSISTOR
SQ USE
Q 302
2SD601A/R/-X
TRANSISTOR
SQ USE
Q 701
2SC2412K/R/-X
TRANSISTOR
Q 951
DTA114EKA-X
DIGITAL.TRANSIS
Q 959
DTC114EKA-X
TRANSISTOR
Q 960
2SA1037AK/RS/-X
TRANSISTOR
Q 961
2SA1037AK/RS/-X
TRANSISTOR
Q 962
2SB1322/RS/-T
TRANSISTOR
Q 963
2SA1037AK/RS/-X
TRANSISTOR
Q 964
DTC114EKA-X
TRANSISTOR
Q 965
DTC114EKA-X
TRANSISTOR
Q 966
DTC114EKA-X
TRANSISTOR
Q 967
2SA1037AK/RS/-X
TRANSISTOR
Q 978
DTC114EKA-X
TRANSISTOR
Q 979
DTA114EKA-X
DIGITAL.TRANSIS
Q 980
DTC114EKA-X
TRANSISTOR
Q 981
DTA114EKA-X
DIGITAL.TRANSIS
R 3
NRSA02J-472X
MG RESISTOR
R 4
NRSA02J-473X
MG RESISTOR
R 5
NRSA02J-332X
MG RESISTOR
R 7
NRSA02J-473X
MG RESISTOR
R 8
NRSA02J-472X
MG RESISTOR
R 9
NRSA02J-102X
MG RESISTOR
R 10
NRSA02J-392X
MG RESISTOR
R 12
NRSA02J-102X
MG RESISTOR
R 14
NRS181J-471X
MG RESISTOR
R 24
NRSA02J-102X
MG RESISTOR
R 25
NRSA02J-102X
MG RESISTOR
R 26
NRSA02J-103X
MG RESISTOR
R 27
NRSA02J-102X
MG RESISTOR
R 29
NRSA02J-152X
MG RESISTOR
R 30
NRS181J-120X
MG RESISTOR
R 34
NRSA02J-223X
MG RESISTOR
R 101
NRSA02J-153X
MG RESISTOR
R 103
NRSA02J-101X
MG RESISTOR
R 104
NRSA02J-334X
MG RESISTOR
R 112
NRSA02J-223X
MG RESISTOR
R 113
NRSA02J-222X
MG RESISTOR
R 132
NRSA02J-222X
MG RESISTOR
R 135
NRSA02J-101X
MG RESISTOR
R 136
NRSA02J-102X
MG RESISTOR
R 141
NRSA02J-153X
MG RESISTOR
R 142
NRSA02J-153X
MG RESISTOR
R 143
NRSA02J-393X
MG RESISTOR
R 144
NRSA02J-393X
MG RESISTOR
R 151
NRSA02J-103X
MG RESISTOR
R 152
NRSA02J-223X
MG RESISTOR
R 153
NRSA02J-472X
MG RESISTOR
R 201
NRSA02J-153X
MG RESISTOR
R 203
NRSA02J-101X
MG RESISTOR
R 204
NRSA02J-334X
MG RESISTOR
R 212
NRSA02J-223X
MG RESISTOR
R 213
NRSA02J-222X
MG RESISTOR
R 232
NRSA02J-222X
MG RESISTOR
R 235
NRSA02J-101X
MG RESISTOR
R 236
NRSA02J-102X
MG RESISTOR
R 241
NRSA02J-153X
MG RESISTOR
R 242
NRSA02J-153X
MG RESISTOR
R 243
NRSA02J-393X
MG RESISTOR
R 244
NRSA02J-393X
MG RESISTOR
R 251
NRSA02J-103X
MG RESISTOR
R 252
NRSA02J-223X
MG RESISTOR
R 253
NRSA02J-472X
MG RESISTOR
R 301
NRSA02J-473X
MG RESISTOR
SQ USE
R 302
NRSA02J-473X
MG RESISTOR
SQ USE
R 303
NRSA02J-103X
MG RESISTOR
SQ USE
R 304
NRSA02J-222X
MG RESISTOR
SQ USE
R 305
NRSA02J-153X
MG RESISTOR
SQ USE
R 306
NRSA02J-471X
MG RESISTOR
SQ USE
R 307
NRSA02J-103X
MG RESISTOR
SQ USE
R 701
NRSA02J-271X
MG RESISTOR
R 702
NRS181J-271X
MG RESISTOR
R 703
NRS181J-271X
MG RESISTOR
R 704
NRSA02J-271X
MG RESISTOR
R 705
NRSA02J-103X
MG RESISTOR
R 706
NRSA02J-473X
MG RESISTOR
R 708
NRSA02J-104X
MG RESISTOR
R 709
NRSA02J-104X
MG RESISTOR
R 710
NRS181J-103X
MG RESISTOR
R 711
NRSA02J-391X
MG RESISTOR
R 712
NRS181J-103X
MG RESISTOR
R 713
NRSA02J-103X
MG RESISTOR
R 715
NRS181J-103X
MG RESISTOR
R 716
NRS181J-103X
MG RESISTOR
R 717
NRS181J-103X
MG RESISTOR
R 718
NRS181J-472X
MG RESISTOR
R 719
NRSA02J-472X
MG RESISTOR
R 720
NRSA02J-472X
MG RESISTOR
R 721
NRS181J-472X
MG RESISTOR
R 722
NRSA02J-472X
MG RESISTOR
R 723
NRS181J-472X
MG RESISTOR
R 724
NRS181J-472X
MG RESISTOR
R 725
NRS181J-472X
MG RESISTOR
R 726
NRS181J-472X
MG RESISTOR
R 727
NRSA02J-472X
MG RESISTOR
R 733
NRS181J-472X
MG RESISTOR
R 734
NRSA02J-472X
MG RESISTOR
R 736
NRSA02J-103X
MG RESISTOR
R 737
NRSA02J-473X
MG RESISTOR
R 738
NRSA02J-473X
MG RESISTOR
R 740
NRSA02J-473X
MG RESISTOR
R 743
NRSA02J-103X
MG RESISTOR
SQ USE
R 746
NRSA02J-473X
MG RESISTOR
R 748
NRSA02J-473X
MG RESISTOR
INTI. RES.
R 750
NRSA02J-473X
MG RESISTOR
INTI. RES.
R 751
NRSA02J-104X
MG RESISTOR
R 752
NRSA02J-334X
MG RESISTOR
R 753
NRSA02J-223X
MG RESISTOR
R 754
NRSA02J-101X
MG RESISTOR
KS-FX453R/FX450
R 755
NRSA02J-103X
MG RESISTOR
KS-FX453R/FX450
Item
Parts number
Parts name
Area
A
Remarks
R
R
R
(Main board)
