KS-FX711/KS-FX511
2-1
Block diagram
LINE
OUT
SPK
BATT
CP981
CJ321
TU1
TUNER
PACK
IC701
CPU
IC801
J-BUS
IC902
REG
IC301
POWER
REGULATOR
IC161
E.VOL
CP8001
CD-CH
CP701
CJ403 CJ402
CJ401
PLAYBACK
HEAD
SWITCH
SUB
MOTOR
MAIN
MOTOR
IC402
DRIVER
IC401
EQ AMP
FWD_L
FWD_R
REV_L
REV_R
SUBMO+
SUBMO-
SUBMO+
SUBMO-
TAPEIN,MODE,REEL
MOTOR,STANDBY
FF/REW
F/R
DOLBY
MSOUT
Lch,Rch
CJ701
CP701
IC652
REMOCON
IC651
LCD
DRIVER
LCD
KEY
MATRIX
S3~S52
COM1~COM3
REMOCON
CLOCK
KEY0~KEY2
J1
ANT
TU_L
TU_R
TAPE_L,TAPE_R
JBUS.SI
JBUS.SO
JBUS.IO
JBUS.INT
JBUS.SCK
EVOLCLK
EVOLDA
EO,FM/AMOSC,IFC,MONO
IFREQ,S.METER,SD/ST
CH_L
CH_R
OUTLR
OUTRR
OUTLF
OUTLR
OUTRF
OUTRR
to
each
BLOCK
