KS-FX711/KS-FX511
3-10
Item
Parts number Parts name Ar
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
a
Remarks
A
B 79 ISS254-T2 DIODE
C 1 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 2 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 4 QDVB1EZ-223Y C CAPACITOR
C 6 QDYB1CM-103Y C CAPACITOR
C 8 QCBB1HK-121Y C CAPACITOR 120PF 10% 50V
C 9 QEKJ1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 10 QDGB1HK-102Y C CAPACITOR
C 12 QDYB1CM-103Y C CAPACITOR
C 13 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 31 QEKJ1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 32 QEKJ1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 33 QEQF1HM-225Z NP E CAPACITOR 2.2MF 20% 50V
C 34 QDGB1HK-102Y C CAPACITOR
C 35 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 81 QDX11EK-183Z C CAPACITOR
C 82 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 91 QDX11EK-183Z C CAPACITOR
C 92 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 162 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 163 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 164 QFLA1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 165 QFV61HJ-154Z MF CAPACITOR 0.15MF 5% 50V
C 166 QFV61HJ-224Z MF CAPACITOR 0.22MF 5% 50V
C 167 QFV61HJ-333Z MF CAPACITOR 0.033MF 5% 50V
C 168 QDXB1CM-682Y C CAPACITOR
C 172 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 173 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 174 QFLA1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 175 QFV61HJ-154Z MF CAPACITOR 0.15MF 5% 50V
C 176 QFV61HJ-224Z MF CAPACITOR 0.22MF 5% 50V
C 177 QFV61HJ-333Z MF CAPACITOR 0.033MF 5% 50V
C 178 QDXB1CM-682Y C CAPACITOR
C 181 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 182 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 191 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 192 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 195 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 196 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 197 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 198 QDYB1CM-103Y C CAPACITOR
C 199 QCFB1HZ-104Y C CAPACITOR 0.1MF +80:-20%
C 241 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 242 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 243 QCFB1HZ-473Y C CAPACITOR 0.047MF +80:-20%
C 244 QERF1HM-474Z E CAPACITOR 0.47MF 20% 50V
C 301 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 302 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 303 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 304 QCBB1HK-223Y C CAPACITOR 0.022MF 10% 50V
C 305 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 306 QCFB1HZ-104Y C CAPACITOR 0.1MF +80:-20%
C 307 QCFB1HZ-104Y C CAPACITOR 0.1MF +80:-20%
C 308 QCFB1HZ-104Y C CAPACITOR 0.1MF +80:-20%
C 309 QCFB1HZ-104Y C CAPACITOR 0.1MF +80:-20%
C 321 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 322 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 331 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 332 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 341 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 342 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 351 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 352 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 701 QDUB1HJ-270Y C CAPACITOR
C 702 QDCB1HJ-220Y C CAPACITOR
C 703 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 704 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 705 QFV61HJ-224Z MF CAPACITOR 0.22MF 5% 50V
C 707 QCFB1HZ-104Y C CAPACITOR 0.1MF +80:-20%
C 711 QCBB1HK-103Y C CAPACITOR 0.01MF 10% 50V
C 713 QCBB1HK-103Y C CAPACITOR 0.01MF 10% 50V
C 781 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 782 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 801 QCFB1HZ-473Y C CAPACITOR 0.047MF +80:-20%
C 901 QEZ0518-228 E CAPACITOR 2200MF
C 902 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 903 QERF1AM-106Z E CAPACITOR 10MF 20% 10V
C 904 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 905 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 906 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 907 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 909 QDYB1CM-103Y C CAPACITOR
C 910 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 911 QFV61HJ-104Z MF CAPACITOR 0.1MF 5% 50V
C 912 QEZ0423-228 E CAPACITOR 2200MF
C 917 QFV11HJ-334AZ MF CAPACITOR 0.33MF 5% 50V
CJ321 QNN0170-001 PIN JACK
CJ701 VMC0334-001 CONNECTOR
CP701 QGB1214J1-18S CONNECTOR
CP801 QNZ0095-001 CONNECTOR
CP981 QNZ0002-001 JACK UNIT
D 1 1SS133-T2 SI DIODE
D 2 1SS133-T2 SI DIODE
D 10 RB721Q-T2 S.B.DIODE
D 31 MTZJ9.1C-T2 ZENER DIODE
D 32 1SS133-T2 SI DIODE
D 241 RB721Q-T2 S.B.DIODE
D 242 RB721Q-T2 S.B.DIODE
D 310 1SS133-T2 SI DIODE
D 321 1SS254-T2 SI DIODE
D 701 1SS133-T2 SI DIODE KS-FX711
D 702 1SS133-T2 SI DIODE
D 704 1SS133-T2 SI DIODE
D 705 MTZJ5.6B-T2 ZENER DIODE
D 706 MTZJ5.6B-T2 ZENER DIODE
D 707 MTZJ5.6B-T2 ZENER DIODE
D 708 MTZJ5.6B-T2 ZENER DIODE
D 709 MTZJ5.6B-T2 ZENER DIODE
D 710 MTZJ5.6B-T2 ZENER DIODE
D 711 MTZJ5.6B-T2 ZENER DIODE
D 715 MTZJ5.6B-T2 ZENER DIODE
D 760 RB721Q-T2 DIODE
D 781 1SS254-T2 SI DIODE
D 782 MTZJ11B-T2 ZENER DIODE
D 901 1N5401-F64 SI DIODE
D 902 1SS254-T2 SI DIODE
D 903 DSK10C-T1 DIODE
D 904 DSK10C-T1 DIODE
IC161 TEA6320T-X IC
IC301 LA4743K IC
IC701 LC72366-9A74 IC
IC801 HD74HC126P IC
IC901 AN80T05 IC
IC902 KIA7810PI 10V REGULATOR
J 1 QNB0100-002 ANT TERMINAL
L 1 QQL231K-4R7Y INDUCTOR
