KS-FX711/KS-FX511
Adjustment method
Test instruments reqired for adjustment
1. Digital osclloscope(100MHz)
2. Frequency Counter meter
3. Electric voltmeter
4. Wow & flutter meter
5. Test Tapes
VT724 .......................
...................
for DOLBY level measurement
VT739 ............For playback frequency measurement
VT712 ....For wow flutter & tape speed measurement
VT703 ..................... For head azimuth measurement
6. Torque gauge .................... Cassette type for CTG-N
(mechanism adjustment)
Measuring conditions(Amplifier section)
Power supply voltage .............. DC14.4V (11V to 16V allowance)
Load impedance ........... 4 (4 to 8 allownce)
Line out level/impedance ...............................
Standard volume position
Balance and Bass,Treble volume .Fader
:Center(Indication"0")
Loudness,Dolby NR,Sound,Cruise:Off
Volume position is about 2V at speaker output with
following conditions.Playback the test tape VT721.
AM mode 531kHz to 1602kHz
FM mode 87.5 MHz to 108.0 MHz
MC-109C
for TAPA CURL confirmation
(without Padd type)
2.0V/20k load (250 nWb/m)
