KS-FX711/KS-FX511
3-11
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
L 718 QQL231K-470Y INDUCTOR
L 901 QQR0703-001 CHOKE COIL
L 902 QQL231K-470Y INDUCTOR
L 903 QQL231K-470Y INDUCTOR
Q
4 KRC102M-T D.TRANSISTOR
Q
31 KTC3199/GL/-T TRANSISTOR
Q
32 KTC3199/GL/-T TRANSISTOR
Q
241 KTC3199/GL/-T TRANSISTOR
Q
301 KRC102M-T D.TRANSISTOR
Q
321 2SD2144S/VW/-T TRANSISTOR
Q
351 2SD2144S/VW/-T TRANSISTOR
Q
701 KTC3199/GL/-T TRANSISTOR
Q
781 KRA102M-T D.TRANSISTOR
Q
782 KRA102M-T D.TRANSISTOR
Q
901 KTA1267/YG/-T TRANSISTOR
Q
902 KRC102M-T D.TRANSISTOR
Q
903 KRA102M-T D.TRANSISTOR
Q
904 KRC102M-T D.TRANSISTOR
Q
905 2SA1855/RST/-T TRANSISTOR
Q
906 KRC102M-T D.TRANSISTOR
Q
907 KTA1267/YG/-T TRANSISTOR
Q
976 KTA1267/YG/-T TRANSISTOR
Q
977 KTC3199/GL/-T TRANSISTOR
R 1 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 4 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 6 QRE141J-820Y C RESISTOR 82 5% 1/4W
R 7 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 8 QRE141J-822Y C RESISTOR 8.2K 5% 1/4W
R 9 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 11 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 31 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 32 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 33 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 34 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 35 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 36 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 81 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 82 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 91 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 92 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 161 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 162 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 163 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 164 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 171 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 172 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 173 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 174 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R 195 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 241 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 242 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R 243 QRE141J-184Y C RESISTOR 180K 5% 1/4W
R 244 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 245 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 246 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 247 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 248 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 301 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 302 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 303 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 321 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 322 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 325 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 331 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 332 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 341 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 342 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 343 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 344 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 351 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 352 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 353 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 354 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 355 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 701 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 702 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 703 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 704 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 705 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 706 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 707 QRE141J-473Y C RESISTOR KS-FX711
R 708 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 709 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 710 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 711 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 712 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 713 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 714 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 716 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 717 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 718 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 719 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 720 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 721 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 722 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 723 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 724 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 725 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 727 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 728 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 729 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 730 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 731 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 733 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 734 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 735 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 736 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 737 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 738 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 743 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 750 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R 801 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 802 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 803 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 804 QRE141J-334Y C RESISTOR 330K 5% 1/4W
R 805 QRE141J-334Y C RESISTOR 330K 5% 1/4W
R 806 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 807 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 808 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 809 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 810 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 811 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 812 QRE141J-242Y C RESISTOR 2.4K 5% 1/4W
R 813 QRE141J-242Y C RESISTOR 2.4K 5% 1/4W
R 814 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 901 QRE141J-101Y C RESISTOR 100 5% 1/4W
