Item
Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty
Description
Block No. MPMM
65 1-0802-4007S
GEAR BASE SPG
1
66 1-0802-4008S
REEL DRIVER SPG
2
67 1-0802-4013S
COMPULSION SPG
1
71 1-0802-5001S
BELT
1
72 1-0802-5002S
FELT
1
7.5*18.5*1.0
73 1-0802-5003S
AZIMUTH SCREW
2
74 1-0802-5004S
FELT
1
11*18.5*1.0
75 1-0050-5023S
WIRE CLAMPER
1
82 1-0802-7001S
REEL PCB DL
1
83 1-0802-7010S
SWITCH(MATSUSIT
1
ESE22MH32
84 1-0802-7003S
SWITCH(MIC)
1
MPU11750MLBO
85 1-0802-7016S
FLAT CABLE 10P
1
10P-JVC
86 1-0801-7024S
PHOTO SENSOR(MA
1
ON2170-QR FS
87 1-0802-7009S
SWITCH(MIC)
1
MPU12370MLB0
91 1-0802-7007S
HEAD(MITSUMI)
1
P-5344-CB-4152
93 1-0801-7009-0S
M.MOTOR WIRE
1
BLACK
94 1-0801-7009-1S
M.MOTOR WIRE
1
RED
97 1-0802-7012-0S
HEAD WIRE
1
BLACK
98 1-0802-7012-1S
HEAD WIRE
1
BROWN
99 1-0802-7012-2S
HEAD WIRE
1
RED
100 1-0802-7012-3S
HEAD WIRE
1
ORANGE
101 1-0802-7012-4S
HEAD WIRE
1
YELLOW
102 1-0802-7012-5S
HEAD WIRE
1
WHITE
103 1-0802-7008S
HEAD PCB
1
104 1-0801-7025S
CONNECTOR
1
S6B-PH-K-S(JST)
106 2-1032-0025-C2S
SCREW
2
M2*2.5 #3
107 2-13S2-0025-P2S
+PLAIN SCREW
2
M2*2.5 #2S
108 2-1112-6035-C2S
+PLAIN SCREW
1
M2.6*3.5 #3
109 2-1816-0032-E8S
LMW-S
2
1.6*3.2*0.35
110 2-1812-0032-D2S
PSW-S
1
1.2*3.2*0.25
111 1-0036-5024S
PSW-S(REEL B)
3
1.5*3.2*0.25
113 2-1821-0040-D1S
PSW
2
2.1*4.0*0.25
114 2-1821-0040-D2S
PSW-S
3
2.1*4.0*0.25
116 2-1711-5040-16S
E RING
1
117 2-1031-7030-C2S
SCREW
2
M1.7*3.0 #3
118 2-1332-0035-P1S
SCREW
1
M2*3.5
