KS-FX711/KS-FX511
3-13
Item
Parts number Parts name Ar
e
a
Electrical parts list (Front board)
Remarks
Block No. 02
A
C 651 NCB21HK-103X C CAPACITOR
C 652 NBE20JM-475X TS E CAPACITOR
C 653 NCB21HK-681X C CAPACITOR
C 654 NBE20JM-475X TS E CAPACITOR KS-FX711
CP701 VMC0335-001 CONNECTOR
D 601 SML-310LT/MN/-X LED
D 602 LNJ308G81/1-3/X LED
D 603 LNJ308G81/1-3/X LED
D 604 LNJ308G81/1-3/X LED
D 605 LNJ308G81/1-3/X LED
D 606 LNJ308G81/1-3/X LED
D 607 LNJ308G81/1-3/X LED
D 608 SML-310VT/JK/-X LED
D 609 LNJ308G81/1-3/X LED
D 610 LNJ308G81/1-3/X LED
D 611 LNJ308G81/1-3/X LED
D 612 LNJ308G81/1-3/X LED
D 613 LNJ308G81/1-3/X LED
D 614 LNJ308G81/1-3/X LED
D 615 LNJ308G81/1-3/X LED
D 616 LNJ308G81/1-3/X LED
D 617 LNJ308G81/1-3/X LED
D 618 LNJ308G81/1-3/X LED
D 619 LNJ308G81/1-3/X LED
D 620 LNJ308G81/1-3/X LED
D 652 MA152WA-X DIODE
D 653 MA152WA-X DIODE
D 654 MA152WK-X SI DIODE
D 655 MA152WK-X SI DIODE
D 657 MA3062/H/-X ZENER DIODE KS-FX711
IC651 PT6523LQ IC
IC652 RPM6938-SV4 IC KS-FX711
PL601 QLL0033-003 LAMP
PL603 QLL0033-003 LAMP
R 601 NRSA63J-681X MG RESISTOR
R 602 NRSA63J-561X MG RESISTOR
R 603 NRSA63J-681X MG RESISTOR
R 604 NRSA63J-911X MG RESISTOR
R 605 NRSA63J-122X MG RESISTOR
R 607 NRSA63J-681X MG RESISTOR
R 608 NRSA63J-561X MG RESISTOR
R 609 NRSA63J-681X MG RESISTOR
R 610 NRSA63J-911X MG RESISTOR
R 611 NRSA63J-122X MG RESISTOR
R 612 NRSA63J-152X MG RESISTOR
R 613 NRSA63J-681X MG RESISTOR
R 614 NRSA63J-561X MG RESISTOR
R 615 NRSA63J-681X MG RESISTOR
R 616 NRSA63J-911X MG RESISTOR
R 617 NRSA63J-122X MG RESISTOR
R 618 NRSA63J-152X MG RESISTOR
R 635 NRSA02J-821X MG RESISTOR
R 636 NRSA02J-821X MG RESISTOR
R 637 NRSA02J-821X MG RESISTOR
R 638 NRSA02J-511X MG RESISTOR
R 639 NRSA02J-511X MG RESISTOR
R 640 NRSA02J-152X MG RESISTOR
R 641 NRSA02J-152X MG RESISTOR
R 642 NRSA02J-221X MG RESISTOR
R 643 NRSA02J-221X MG RESISTOR
R 644 NRSA02J-221X MG RESISTOR
R 645 NRSA02J-221X MG RESISTOR
R 646 NRSA02J-511X MG RESISTOR
R 647 NRSA02J-511X MG RESISTOR
R 648 NRSA02J-821X MG RESISTOR
R 649 NRSA02J-821X MG RESISTOR
R 651 NRSA02J-152X MG RESISTOR
R 652 NRSA02J-473X MG RESISTOR
R 653 NRSA02J-184X MG RESISTOR
R 654 NRSA02J-103X MG RESISTOR
R 655 NRSA02J-103X MG RESISTOR
R 656 NRSA02J-103X MG RESISTOR
R 657 NRSA63J-103X MG RESISTOR KS-FX711
R 658 NRSA63J-470X MG RESISTOR KS-FX711
S 601 NSW0124-001X TACT SWITCH
S 602 NSW0124-001X TACT SWITCH
S 603 NSW0124-001X TACT SWITCH
S 604 NSW0124-001X TACT SWITCH
S 605 NSW0124-001X TACT SWITCH
S 606 NSW0124-001X TACT SWITCH
S 608 NSW0124-001X TACT SWITCH
S 609 NSW0124-001X TACT SWITCH
S 610 NSW0124-001X TACT SWITCH
S 611 NSW0124-001X TACT SWITCH
S 612 NSW0124-001X TACT SWITCH
S 613 NSW0124-001X TACT SWITCH
S 614 NSW0124-001X TACT SWITCH
S 615 NSW0124-001X TACT SWITCH
S 616 NSW0124-001X TACT SWITCH
S 617 NSW0124-001X TACT SWITCH
S 618 NSW0124-001X TACT SWITCH
S 619 NSW0124-001X TACT SWITCH
S 620 NSW0124-001X TACT SWITCH
S 621 NSW0124-001X TACT SWITCH
Item
Parts number Parts name Ar
e
a
Remarks
A
