JVC LT-19DA9 Series Service Manual

(No.YA606<Rev.002>)1-17
Video Setup
CVBS(EXT-4)
Standard
Brightness 0 - 100 41 Adjust the Brightness value of Standard mode in CVBS(EXT-4).
Contrast 0 - 100 68 Adjust the Contrast value of Standard mode in CVBS(EXT-4).
Sharpness 0 - 100 65 Adjust the Sharpness value of Standard mode in CVBS(EXT-4).
Colour 0 - 100 58 Adjust the Colour value of Standard mode in CVBS(EXT-4).
Farbton 0 - 100 0 Adjust the Farbton value of Standard mode in CVBS(EXT-4).
Bright
Brightness 0 - 100 41 Adjust the Brightness value of Bright mode in CVBS(EXT-4).
Contrast 0 - 100 73 Adjust the Contrast value of Bright mode in CVBS(EXT-4).
Sharpness 0 - 100 65 Adjust the Sharpness value of Bright mode in CVBS(EXT-4).
Colour 0 - 100 59 Adjust the Colour value of Bright mode in CVBS(EXT-4).
Farbton 0 - 100 0 Adjust the Farbton value of Bright mode in CVBS(EXT-4).
Game
Brightness 0 - 100 43 Adjust the Brightness value of Bright mode in CVBS(EXT-4).
Contrast 0 - 100 63 Adjust the Contrast value of Bright mode in CVBS(EXT-4).
Sharpness 0 - 100 65 Adjust the Sharpness value of Bright mode in CVBS(EXT-4).
Colour 0 - 100 58 Adjust the Colour value of Bright mode in CVBS(EXT-4).
Farbton 0 - 100 0 Adjust the Farbton value of Bright mode in CVBS(EXT-4).
Soft
Brightness 0 - 100 42 Adjust the Brightness value of Soft mode in CVBS(EXT-4).
Contrast 0 - 100 63 Adjust the Contrast value of Soft mode in CVBS(EXT-4).
Sharpness 0 - 100 65 Adjust the Sharpness value of Soft mode in CVBS(EXT-4).
Colour 0 - 100 58 Adjust the Colour value of Soft mode in CVBS(EXT-4).
Farbton 0 - 100 0 Adjust the Farbton value of Soft mode in CVBS(EXT-4).
Video Setup
RGB(Digital TV
EXT-1 EXT-2)
Standard
Brightness 0 - 100 41 Adjust the Brightness value of Standard mode in RGB(Digital TV EXT-1 EXT-2).
Contrast 0 - 100 68 Adjust the Contrast value of Standard mode in RGB(Digital TV EXT-1 EXT-2).
Sharpness 0 - 100 65 Adjust the Sharpness value of Standard mode in RGB(Digital TV EXT-1 EXT-2).
Colour 0 - 100 58 Adjust the Colour value of Standard mode in RGB(Digital TV EXT-1 EXT-2).
Farbton 0 - 100 0 Adjust the Farbton value of Standard mode in RGB(Digital TV EXT-1 EXT-2).
Bright
Brightness 0 - 100 41 Adjust the Brightness value of Bright mode in RGB(Digital TV EXT-1 EXT-2).
Contrast 0 - 100 73 Adjust the Contrast value of Bright mode in RGB(Digital TV EXT-1 EXT-2).
Sharpness 0 - 100 65 Adjust the Sharpness value of Bright mode in RGB(Digital TV EXT-1 EXT-2).
Colour 0 - 100 59 Adjust the Colour value of Bright mode in RGB(Digital TV EXT-1 EXT-2).
Farbton 0 - 100 0 Adjust the Farbton value of Bright mode in RGB(Digital TV EXT-1 EXT-2).
Game
Brightness 0 - 100 43 Adjust the Brightness value of Game mode in RGB(Digital TV EXT-1 EXT-2).
Contrast 0 - 100 63 Adjust the Contrast value of Game mode in RGB(Digital TV EXT-1 EXT-2).
Sharpness 0 - 100 65 Adjust the Sharpness value of Game mode in RGB(Digital TV EXT-1 EXT-2).
Colour 0 - 100 58 Adjust the Colour value of Game mode in RGB(Digital TV EXT-1 EXT-2).
Farbton 0 - 100 0 Adjust the Farbton value of Game mode in RGB(Digital TV EXT-1 EXT-2).
Soft
Brightness 0 - 100 42 Adjust the Brightness value of Soft mode in RGB(Digital TV EXT-1 EXT-2).
Contrast 0 - 100 63 Adjust the Contrast value of Soft mode in RGB(Digital TV EXT-1 EXT-2).
Sharpness 0 - 100 65 Adjust the Sharpness value of Soft mode in RGB(Digital TV EXT-1 EXT-2).
Colour 0 - 100 58 Adjust the Colour value of Soft mode in RGB(Digital TV EXT-1 EXT-2).
Farbton 0 - 100 0 Adjust the Farbton value of Soft mode in RGB(Digital TV EXT-1 EXT-2).
Swetting item
Variable
range
Default
Value
Comment
