2
8
Preparation
GB
Front View and Rear View Controls
Item Description
1 POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate in blue and then blink in red and blue, confirming that a
timer recording programme has started in standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 INPUT
Press to select among different input signal sources:
DTV / ATV / AV / SCART / YPbPr / HDMI1 / HDMI2 / PC / USB.
Confirmed selection on the OSD menu.
4 MENU Displays the OSD (on screen display) menu.
5 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
6 VOL + / –
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
7
Switches the TV on from standby mode.
Switches the TV back to standby mode.
1 2
4
3
7
6
5
