JVC LT-22HG45E Service Manual

GENERAL SPECIFICATIONS
G-1 TV
LCD LCD Size / Visual Size 21.53 inch / 546.8mmV
System
LCD Type Color TFT LCD
Number of Pixels 1920(H) x 1080(V)
Double Scan No
View Range Left/Right 85/85 degree
Up/Down 80/80 degree
Bright Dot
n ≦ 3
Zero Bright Dot Ratio 70% above
Color System PAL / SECAM
Speaker 2 Speaker
Position Bottom
Size 1.0 x 2.7 inch
Impedance 8 ohm
Sound Output MAX 2.0W + 2.0W
10%(Typical) ---
NTSC3.58+4.43 /PAL60Hz Yes
G-2 Tuning
Broadcasting System Analog
System
Digital
DVB-T
DVB-T
Tuner and System 1Tuner (Analog+Digital)
Receive CH Destination UK, I.R., CCIR Hyper+France CATV
CH Coverage Analog 45.75~858MHz
Digital E2~E69
Intermediate Analog
Frequency Picture(FP) 38.9 / 38.9 / 38.9MHz
Sound(FS)
33.4 / 32.9 / 32.4MHz
FP-FS
5.5 / 6.0 / 6.5MHz
Digital
Auto Tuning Method
ALL Band (Not C.C.I.R. CH Plan)
Preset CH 4000 Service in total of Analog and Digital.
Stereo/Dual TV Sound Nicam/A2 Dual
Tuner Sound Muting Yes
G-3 Power
Power Source AC 220-240V AC 50Hz
DC ---
Power Consumption at AC 31 W at AC 230 V 50 Hz
at DC --
Stand by (at AC) w/ EPG Timer --
w/o EPG Timer 0.49 W at AC 230 V 50 Hz
Per Year -- kWh/Year
Protector Power Fuse Yes
G-4 Regulation
Safety CE(EN60065:2002+AMD.11:2008)
Radiation CE
X-Radiation ---
G-5 Temperature
Operation
+5
o
C ~ +40
o
C
Storage
-20
o
C ~ +60
o
C
Space Around Unit 100mm (4inch)
G-6 Operating Humidity
Less than 80% RH
G-7 OSD Language
English, Spanish, German, French, Italian, Swedish
Dutch, Russian, Portuguese, Turkish, Greek, Finnish
Hungarian, Polish, Danish, Norwegian, Czech, Slovak
G-8 Clock and
Sleep Timer Max Time 120 Min
Timer
Step 10 / 20 / 30 / 40 / 50 / 60 / 90 / 120 Min
On/Off Timer Program(On Timer / Off Timer) 1 Program / 1 Program
Timer Back-up (at Power Off Mode) more than -- Min Sec
EPG Timer Events --
PAL(B/G, D/K, I), SECAM(B/G, D/K)
BG / II / DK
DVB-T 36.167MHz
DVB-C 36.125MHz
