3-4(No.YA327)

EXPLODED VIEW PARTS LIST -1

 Ref.No. Part No. Part Name Description Local

101 LC12319-001A-0K JACK COVER R LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

101 LC12325-001A JACK COVER R LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

102 LC12319-002A-0K JACK COVER L LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

102 LC12325-001A JACK COVER L LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 103 LC21503-001A-H RATING LABEL LT-Z26SX5

 103 LC21503-003A-H RATING LABEL LT-Z26SX5/A

 103 LC21503-002A-H RATING LABEL LT-Z26SX5/S

 103 LC21562-001A-0L RATING LABEL LT-Z32SX5

 103 LC21562-003A-0L RATING LABEL LT-Z32SX5/A

 103 LC21562-002A-0L RATING LABEL LT-Z32SX5/S

104 LC41424-002A HDMI WARNING

105 LC33167-003A OPERATION SHEET

106 LC33168-003B OPERATION SHEET

107 LC42220-001A-C STAND ASSY Inc.107A-107B

107A T0014-01 STAND COVER

107B T0016-02 CORD COVER

108 QYSPSPD5014MA SCREW M5 x 14mm(x4)

109 QYSPSPD3016ZA SCREW M3 x 16mm(x2)

 110 LC32760-001A-HK SERVICE COVER

111 QYSBSF3010MA TAP SCREW M3 x 10mm

112 QYSBSF3010MA TAP SCREW M3 x 10mm(x2)

113 QYSPSPD3008MA SCREW M3 x 8mm

114 QYSBSFG4016MA TAP SCREW M4 x 16mm(x7)

115 LC41999-004A-H CAUTION LABEL LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

115 LC41999-002A CAUTION LABEL LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 116 LC12409-003A-0K REAR COVER LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 116 LC12408-003A REAR COVER LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 117 QMPK300-170-JC POWER CORD(EU) 1.7m BLACK LT-Z26SX5,LT-Z32SX5

 117 QMPG110-170-JC POWER CORD(AST) 1.7m BLACK LT-Z26SX5/A,LT-Z32SX5/A

 117 QMPN260-170-JC POWER CORD(EK) 1.7m BLACK LT-Z26SX5/S,LT-Z32SX5/S

 118 LC21348-001D-HK POWER CORD HOLDER

 119 LC21597-006B-H TUNER BASE LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 119 LC21597-006B-HK TUNER BASE LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

120 QYSPSP3008MA SCREW M3 x 8mm

121 QYSPSPD3008MA SCREW M3 x 8mm(x3)

 122 LC21596-005A-HK TERMINAL BASE

123 QYSBSF3010MA TAP SCREW M3 x 10mm(x7)

 124 LC33196-004B-0K CONTROL ASSY LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 124 LC33196-004B CONTROL ASSY LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

125 QUQ105-5004AA-E FFC WIRE 50pin 4cm

126 QUQ105-3004AA-E FFC WIRE 30pin 4cm

127 QUQ105-5013AE-E FFC WIRE 50pin 13cm

128 QUQ105-5013AE-E FFC WIRE 50pin 13cm

129 QUQK12-2106CH-E FFC WIRE 21pin 6cm

130 QQR0491-001 FERRITE CORE (x2) LT-Z26SX5/A,LT-Z26SX5/S,LT-Z32SX5/A,LT-Z32SX5/S

131 QQR0490-001 NOISE FILTER LT-Z26SX5/A,LT-Z26SX5/S,LT-Z32SX5/A,LT-Z32SX5/S

132 QNB0036-001 HEX SCREW (x2)

133 LC42090-002A-H LICENSE LABEL

 200 SFL-9127A-H2 REGULATOR PWB LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 200 LCA90464-11A REGULATOR PWB LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 201 SFL-9027A-H2 MAIN POWER PWB LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 201 LCA90463-11A MAIN POWER PWB LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 202 SFL-4131A-H2 RECEIVER PWB LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 202 LCA90516-01A RECEIVER PWB LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 203 SFL0D333A-H2 DIGITAL SIGNAL PWB LT-Z26SX5

 203 SFL0D339A-H2 DIGITAL SIGNAL PWB LT-Z26SX5/A

 203 SFL0D336A-H2 DIGITAL SIGNAL PWB LT-Z26SX5/S

 203 LCA10557-73A DIGITAL SIGNAL PWB LT-Z32SX5

 203 LCA10557-79A DIGITAL SIGNAL PWB LT-Z32SX5/A

 203 LCA10557-76A DIGITAL SIGNAL PWB LT-Z32SX5/S

 204 SFL-1131A-H2 ANALOG SIGNAL PWB LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 204 LCA90537-01A ANALOG SIGNAL PWB LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S

 205 SFL-7112A-H2 FRONT CONTROL PWB LT-Z26SX5,LT-Z26SX5/A,LT-Z26SX5/S

 205 LCA90469-03A FRONT CONTROL PWB LT-Z32SX5,LT-Z32SX5/A,LT-Z32SX5/S
