JVC LT-Z26SX5 User Manual

(No.YA327)3-41
FRONT CONTROL P.W. BOARD ASS'Y
(LCA90469-03A) (SFL-7112A)
FRONT LED P.W. BOARD ASS'Y
(LCA90470-03B) (SFL-8133A)
MAIN POWER P.W. BOARD ASS'Y
(LCA90463-11A) (SFL-9027A)
R4202 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R4203 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4301 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4302 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4303 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4304 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4305 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4306 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R4307 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4308 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
L3001 NQL79GM-220X COIL 22uH M
L3002 NQL79GM-100X COIL 10uH M
L3503 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3504 NQL79GM-4R7X COIL 4.7uH M
L3506 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3507 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
CN0001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN0002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30)
CN1011 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
CN1012 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)
K3501 NQR0389-003X FERRITE BEADS
K3502 NQR0389-003X FERRITE BEADS
LC3501 NQR0431-001X EMI FILTER 0.22uF 50V Z
 TU3001 QAU0390-001 TUNER
X3501 QAX0773-001Z CRYSTAL 18.432000MHz
 Ref No. Part No. Part Name Description Local
D7011 UDZS6.2B-X Z DIODE
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7011 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7013 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7014 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7016 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7018 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
J7001 QNS0097-001 3.5 JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
S7701 QSW1131-001Z TACT SWITCH CH-
S7702 QSW1131-001Z TACT SWITCH CH+
S7703 QSW1131-001Z TACT SWITCH MENU/OK
S7704 QSW1131-001Z TACT SWITCH TV/VIDEO
S7705 QSW1131-001Z TACT SWITCH VOL+
S7706 QSW1131-001Z TACT SWITCH VOL-
S7707 QSW1131-001Z TACT SWITCH POWER
 Ref No. Part No. Part Name Description Local
IC8752 GP1UM261RK IR DETECT UNIT
Q8703 UN2212-X DIGI TRANSISTOR
Q8704 UN2110-X DIGI TRANSISTOR
Q8710 UN2212-X DIGI TRANSISTOR
Q8711 UN2212-X DIGI TRANSISTOR
D8702 SEL5E20C-T LED POWER
D8705 SELU5E20C-T LED ILLUMINATION
D8706 MA8068-X Z DIODE
D8707 MA8068-X Z DIODE
D8708 MA8068-X Z DIODE
D8709 MA8068-X Z DIODE
 Ref No. Part No. Part Name Description Local
C8752 NEHL1CM-476X E CAPACITOR 47uF 16V M
R8713 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8714 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8721 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R8722 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R8724 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8726 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8755 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9141 BA50BC0FP-X IC
 IC9211 FA5500AN-W IC
IC9501 F9222L-F219 IC
 IC9541 UTCTL431-T IC
IC9602 M62320FP-X IC
IC9901 MP1593DN-X IC
Q9021 2SC3928A/QR/-X TRANSISTOR
Q9211 2SK3522-01-F1 POWER MOS FET
Q9212 2SD601A/QR/-X TRANSISTOR
Q9213 IMD3A-W DIGI TRANSISTOR
Q9215 2SD601A/QR/-X TRANSISTOR
Q9216 UN2212-X DIGI TRANSISTOR
Q9251 UN2213-X DIGI TRANSISTOR
Q9252 UN2212-X DIGI TRANSISTOR
Q9501 2SD601A/QR/-X TRANSISTOR
Q9502 2SK2865-X POWER MOS FET
Q9503 2SD601A/QR/-X TRANSISTOR
Q9504 2SK2018-01S-W POWER MOS FET
Q9506 UN2213-X DIGI TRANSISTOR
Q9541 UN2212-X DIGI TRANSISTOR
Q9602 2SB1188/QR/-W TRANSISTOR
Q9603 UN2212-X DIGI TRANSISTOR
Q9606 2SC3928A/QR/-X TRANSISTOR
Q9901 2SD601A/QR/-X TRANSISTOR
D9021 MA111-X SI DIODE
D9111 S1WB/A/60-4101 BRIDGE DIODE
 D9201 D25XB60 BRIDGE DIODE
D9202 MA111-X SI DIODE
D9205 MA3082/M/-X Z DIODE
D9211 YG972S6R SI DIODE
D9213 MA111-X SI DIODE
D9214 MA111-X SI DIODE
D9215 D1FL20U-X SI DIODE
D9251 MA3100/M/-X Z DIODE
D9252 MA111-X SI DIODE
D9253 MA111-X SI DIODE
D9254 D1FL20U-X SI DIODE
D9301 FME-220A SB DIODE
D9302 FME-220A SB DIODE
D9501 MA8220/M/-X Z DIODE
D9502 MA8110/H/-X Z DIODE
D9503 D1FL20U-X SI DIODE
D9504 D1FL20U-X SI DIODE
D9505 MA8220/M/-X Z DIODE
D9507 D1FL20U-X SI DIODE
D9508 UDZS5.6B-X Z DIODE 1.5k Ω 1/10W J
D9509 SD883-04-X SB DIODE
D9512 D1FS4-X SB DIODE
D9514 PTZ27B-X Z DIODE
D9515 PTZ27B-X Z DIODE
D9542 FCH20A10 SB DIODE
D9543 FCH20A10 SB DIODE
D9546 FCH20A10 SB DIODE
D9609 MA111-X SI DIODE
D9901 EC30HA04-X SB DIODE
D9902 MA111-X SI DIODE
D9903 EC30HA04-X SB DIODE
D9905 D1FL20U-X SI DIODE
D9906 PTZ11B-X Z DIODE
D9907 MTZJ16B-T2 Z DIODE
D9908 MTZJ16B-T2 Z DIODE
D9909 D1FL20U-X SI DIODE
 C9001 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9002 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9011 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9013 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9101 QCZ9082-472Z C CAPACITOR 4700pF AC250V M
 Ref No. Part No. Part Name Description Local
