JVC LT-Z26SX5 - Regulator P.w. Board Assy (Lca90464-11 A) (Sfl-9127 A); Digital Signal P.w. Board Assy (Lca10557-73 A) (Sfl-0 D332 A)

(No.YA327)3-43
REGULATOR P.W. BOARD ASS'Y
(LCA90464-11A) (SFL-9127A)
DIGITAL SIGNAL P.W. BOARD ASS'Y
(LCA10557-73A) (SFL-0D332A)
 CN0007 QGB2501J1-10 CONNECTOR B-B (1-10)
CN000H QGF1201C2-21 CONNECTOR FFC/FPC (1-21)
 CP9121 QMFZ052-2R0-E FUSE 2A AC250V
 CP9211 QMFZ043-2R0Z-J1 FUSE 2A AC250V
 CP9301 QMFZ034-5R0Z-J1 FUSE 5A 125V
 CP9302 QMFZ034-5R0Z-J1 FUSE 5A 125V
 F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9001 QRN143J-0R0X C RESISTOR 0 Ω 1/4W J
K9111 NQR0499-001X FERRITE BEADS
K9211 QQR0621-002Z FERRITE BEADS
K9212 QQR0621-002Z FERRITE BEADS
K9501 NQR0499-002X FERRITE BEADS
K9502 NQR0499-002X FERRITE BEADS
K9503 NQR0499-002X FERRITE BEADS
K9504 NQR0499-002X FERRITE BEADS
K9505 NQR0499-002X FERRITE BEADS
K9508 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K9509 NQR0499-002X FERRITE BEADS
K9541 NQR0499-001X FERRITE BEADS
 LF9001 QQR1514-001 LINE FILTER
 LF9002 QQR1467-001 LINE FILTER
 LF9003 QQR1514-001 LINE FILTER
 PC9541 PS2581AL2/QW/-W PHOTO COUPLER
 PC9542 PS2581AL2/QW/-W PHOTO COUPLER
 RY9021 QSK0162-001 RELAY
 RY9201 QSK0163-001 RELAY
 VA9001 QAF0060-621 VARISTOR 620V
 Ref No. Part No. Part Name Description Local
IC9801 MP1593DN-X IC
IC9821 MP1593DN-X IC
IC9841 MP1593DN-X IC
IC9861 MP1593DN-X IC
IC9881 LM393DR-X IC
Q9801 2SC3928A/QR/-X TRANSISTOR
Q9821 2SC3928A/QR/-X TRANSISTOR
D9802 EC30HA04-X SB DIODE
D9803 MA111-X SI DIODE
D9805 PTZ6.8B-X Z DIODE
D9822 EC30HA04-X SB DIODE
D9823 PTZ6.8B-X Z DIODE
D9824 MA111-X SI DIODE
D9825 EC30HA04-X SB DIODE
D9842 EC30HA04-X SB DIODE
D9843 PTZ3.9B-X Z DIODE
D9861 MA111-X SI DIODE
D9862 EC30HA04-X SB DIODE
D9863 PTZ3.9B-X Z DIODE
D9864 EC30HA04-X SB DIODE
D9881 UDZS9.1B-X Z DIODE
D9882 MA111-X SI DIODE
C9803 NCJ41HK-335X-U C CAPACITOR
C9804 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9805 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9806 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9807 NCB31HK-332X C CAPACITOR 3300pF 50V K
C9810 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9821 NCJ41HK-335X-U C CAPACITOR
C9822 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9825 NDC31HJ-101X C CAPACITOR 100pF 50V J
C9826 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9827 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9830 NBZ0008-107X SP E CAPACITOR 100uF 6.3V M
C9831 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9843 NCJ41HK-335X-U C CAPACITOR
C9844 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9845 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9846 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9847 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9848 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9861 NCJ41HK-335X-U C CAPACITOR
C9862 NCB31HK-822X C CAPACITOR 8200pF 50V K
C9864 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9865 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9866 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9867 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9868 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
 Ref No. Part No. Part Name Description Local
C9881 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9882 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9883 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9884 NCB31EK-104X C CAPACITOR 0.1uF 25V K
R9803 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9804 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R9805 NRVA02D-473X CMF RESISTOR 47k Ω 1/10W D
R9806 NRSA63D-124X MG RESISTOR 120k
Ω 1/16W D
R9807 NRSA63D-103X MG RESISTOR 10k
Ω 1/16W D
R9808 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9809 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R9810 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9812 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9821 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9822 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9823 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R9824 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9825 NRSA63D-473X MG RESISTOR 47k Ω 1/16W D
R9826 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9827 NRSA63D-124X MG RESISTOR 120k Ω 1/16W D
R9828 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9829 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R9830 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R9831 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9841 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9843 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9844 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R9845 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9846 NRSA63D-223X MG RESISTOR 22k Ω 1/16W D
R9847 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R9848 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9849 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9861 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9862 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9863 NRSA63J-824X MG RESISTOR 820k Ω 1/16W J
R9864 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R9865 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9866 NRSA63D-153X MG RESISTOR 15k Ω 1/16W D
R9867 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9868 NRSA63D-154X MG RESISTOR 150k Ω 1/16W D
R9869 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9881 NRS12BJ-332W MG RESISTOR 3.3k Ω 1/2W J
R9882 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R9883 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R9884 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9885 NRSA63D-273X MG RESISTOR 27k Ω 1/16W D
R9886 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
L9802 NQL98EM-150X COIL 15uH M
L9822 NQL71EM-150X COIL 15uH M
L9823 NQR0562-003X CHOKE COIL
L9842 NQL98EM-150X COIL 15uH M
L9862 NQL98EM-150X COIL 15uH M
CN9806 QGB2501K2-07 CONNECTOR B-B (1-7)
CN9807 QGB2501K2-10 CONNECTOR B-B (1-10)
 Ref No. Part No. Part Name Description Local
IC0401 SN74AHCT1G32V-X IC
IC1001 TC90A92AFG IC
IC1002 MM1572FN-X IC
IC1003 R1141Q151D-X IC
IC1005 ML87V2105TBZ03A IC
IC1502 NJM2235V-X IC
IC3001 JCC5055A IC
IC3004 TC7MB3257FK-X IC
IC3005 SN74LVC1G08V-X IC
IC3006 SN74LVC2G126T-X IC
IC3007 SN74LVC3G17U-X IC
IC3008 R1170H331B-X IC
IC3403 S-80928CLNB-G-W IC
IC3501 EDD1232AAFA-7A IC
IC3502 EDD1232AAFA-7A IC
IC3503 LP2996MR-X IC
IC4001 JCC5057 IC
IC4003 AT29LE-Z26SX5 IC(MICRO C ROM) (SERVICE)
IC4004 ATF256-Z32SX5 IC (SERVICE)
IC6502 THC63LVDM83R-W IC
IC7001 MN102H60KKK IC(MCU)
IC7002 ATF512-Z32SX5 IC(MICRO C ROM) (SERVICE)
 Ref No. Part No. Part Name Description Local
