1-2 (No.MB160)
SPECIFICATION
Amplifier section-CA-MXGB6
Speaker section-SP-MXGB6
Design and specifications are subject to change without notice.
Output Power SUBWOOFERS 170 W per channel, min. RMS, driven into 6 Ω at 63 Hz with no more than
10% total harmonic distortion.
MAIN SPEAKERS 80 W per channel, min. RMS, driven into 4 Ω at 1 kHz with no more than
10% total harmonic distortion.
Audio input sensitivity/Impedance
(at 1 kHz, measured at MAIN SPEAKERS)
AUX:400 mV/50 kΩ
Speakers/Impedance Subwoofers 6 Ω - 16 Ω
Main speakers 4 Ω - 8 Ω
Tuner FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player CD Capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Cassette deck Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 120 V , 60 Hz
Power consumption 230 W (at operation)
23.8 W (on standby)
Dimensions (approx.) 270 mm × 317 mm × 480 mm (W/H/D)
(10 11/16 in. × 12 1/2 in. × 18 15/16 in.)
Mass (approx.) 10.5 kg (23.2 lbs)
Type 3-way bass-reflex type
Speaker units Subwoofer 20 cm (7 7/8 in.) cone × 1
Main Woofer 12 cm (4 3/4 in.) cone × 1
Tweeter 5 cm (2 in.) cone × 1
Power handling capacity Subwoofer 170 W
Main speaker 80 W
Impedance Subwoofer 6 Ω
Main speaker 4 Ω
Frequency range Subwoofer 25 Hz - 100 Hz
Main speaker 100 Hz - 20 000 Hz
Sound pressure level Subwoofer 75 dB/W·m
Main speaker 82 dB/W·m
Dimensions (approx.) 233 mm × 456 mm × 360 mm (W/H/D)
(9 3/16 in. × 18 in. × 14 3/16 in.)
Mass (approx.) 6.6 kg (14.6 lbs) each
