JVC MX-GB5 Service Manual

3-12
Front board
Block No. [0][2][0][0]
JR101 2001-000290 C RESISTOR 10KOHM 5% 1/8W
JR102 2001-000456 C RESISTOR 2.2OHM 5% 1/4W
JR103 2001-000023 C RESISTOR 47OHM 5% 1/4W
JR104 2001-000786 C RESISTOR 47KOHM 5% 1/8W
JR105 2001-000591 C RESISTOR 3.3KOHM 5% 1/8W
JR106 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
JR107 2001-000429 C RESISTOR 1KOHM 5% 1/8W
JR108 2001-000290 C RESISTOR 10KOHM 5% 1/8W
JR109 2001-000591 C RESISTOR 3.3KOHM 5% 1/8W
JR110 2001-000281 C RESISTOR 100OHM 5% 1/8W
JR112 2001-000435 C RESISTOR 1MOHM 5% 1/8W
JR113 2001-000522 C RESISTOR 22KOHM 5% 1/8W
JVR01 2001-000010 C RESISTOR 68KOHM 5% 1/8W
JVR02 2001-000010 C RESISTOR 68KOHM 5% 1/8W
 PBD01 GBU606 DIODE 0402-001258
 PBD02 GBU606 DIODE 0402-001258
PD102 1N4002 DIODE 0402-000127 GB5
PD201 1N4002 DIODE 0402-000127
PD202 1N4002 DIODE 0402-000127
PD203 1N4002 DIODE 0402-000127
PD204 1N4002 DIODE 0402-000127
PD205 1N4148 GE DIODE 0401-000101
PD206 1N4148 GE DIODE 0401-000101
PD209 1N4002 DIODE 0402-000127
PD210 1N4002 DIODE 0402-000127
 PD211 1N5392 DIODE 0402-000151
 PD212 1N5392 DIODE 0402-000151
 PD213 1N5392 DIODE 0402-000151
 PD214 1N5392 DIODE 0402-000151
 PE201 2401-003887 E CAPACITOR 2200uF 20% 42V GB5
 PE201 2401-002592 E CAPACITOR 2200uF 20% 50V GB6
 PE202 2401-003887 E CAPACITOR 2200uF 20% 42V GB5
 PE202 2401-002592 E CAPACITOR 2200uF 20% 50V GB6
 PE203 2401-003385 E CAPACITOR 3300uF 20% 80V
PE204 2401-003385 E CAPACITOR 3300uF 20% 80V
 PE205 2401-003116 E CAPACITOR 4700uF 20% 35V
PE206 2401-000830 E CAPACITOR 220uF 20% 25V
PE207 2401-000907 E CAPACITOR 22uF 20% 16V
PE208 2401-000438 E CAPACITOR 10uF 20% 25V
PE209 2401-001912 E CAPACITOR 1uF 20% 50V
PE210 2401-001912 E CAPACITOR 1uF 20% 50V GB5
PE210 2401-000475 E CAPACITOR 10uF 20% 50V GB6
PE211 2401-001954 E CAPACITOR 4.7uF 20% 50V
PE212 2401-000230 E CAPACITOR 100uF 20% 100V
PE213 2401-001954 E CAPACITOR 4.7uF 20% 50V
PE214 2401-000438 E CAPACITOR 10uF 20% 25V
PE215 2401-000778 E CAPACITOR 220uF 20% 10V
 PF101 2008-000135 FUSI.RESISTOR 1OHM 5% 1/2W
PQ102 KSR2002 DIGI TRANSISTOR 0504-000144
PQ103 KTC2874-B TRANSISTOR 0501-002436
PQ104 KSC1009-Y TRANSISTOR 0501-000331
PQ105 KSA928A-Y TRANSISTOR 0501-000610
PQ106 KSA708-Y TRANSISTOR 0501-000294
PQ107 KSA928A-Y TRANSISTOR 0501-000610
PQ108 KTC3199-Y TRANSISTOR 0501-000014
PQ109 KSD1691 TRANSISTOR 0502-001048
PR201 2001-000591 C RESISTOR 3.3KOHM 5% 1/8W
PR202 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
PR203 2001-000429 C RESISTOR 1KOHM 5% 1/8W
PR204 2001-000786 C RESISTOR 47KOHM 5% 1/8W
PR205 2001-000290 C RESISTOR 10KOHM 5% 1/8W
PR206 2003-000455 M.RESISTOR 100OHM 5% 2W
PR207 2001-000563 C RESISTOR 27KOHM 5% 1/8W
PR208 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
PR209 2001-000111 C RESISTOR 150OHM 5% 1/4W
PR210 2001-000055 C RESISTOR 4.7KOHM 5% 1/4W
PR211 2001-000038 C RESISTOR 390OHM 5% 1/4W
PR212 2001-000429 C RESISTOR 1KOHM 5% 1/8W
PR213 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
PR214 2001-000613 C RESISTOR 3.9KOHM 5% 1/8W
PR215 2001-000890 C RESISTOR 6.8KOHM 5% 1/8W
PR216 2003-000701 M.RESISTOR 470OHM 5% 2W
PR217 2001-001153 C RESISTOR 47OHM 5% 1/2W
PR218 2001-001153 C RESISTOR 47OHM 5% 1/2W
PR219 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
PR21A 2001-000290 C RESISTOR 10KOHM 5% 1/8W
PR220 2001-000290 C RESISTOR 10KOHM 5% 1/8W
PR221 2001-000660 C RESISTOR 33KOHM 5% 1/8W
 Symbol No. Part No. Part Name Description Local
PR223 2001-000780 C RESISTOR 470OHM 5% 1/8W
PZ101 UZ5.1B Z DIODE 0403-000354
PZ102 UZP18B Z DIODE 0403-000570
PZ103 UZP18B Z DIODE 0403-000570
PZ104 UZP5.1B Z DIODE 0403-000393
PZ105 UZP13B Z DIODE 0403-000380
PZ106 UZ5.6BM Z DIODE 0403-000357
PZD01 UZ5.1B Z DIODE 0403-000354 GB6
SC01 2301-000419 M CAPACITOR 27nF
SE04 2401-002180 E CAPACITOR 2.2uF 20% 50V
SE05 2401-000438 E CAPACITOR 10uF 20% 25V
SE08 2401-000438 E CAPACITOR 10uF 20% 25V
SE09 2401-001954 E CAPACITOR 4.7uF 20% 50V
SE10 2401-000438 E CAPACITOR 10uF 20% 25V
SE11 2401-000438 E CAPACITOR 10uF 20% 25V
SE12 2401-000438 E CAPACITOR 10uF 20% 25V
SE13 2401-001954 E CAPACITOR 4.7uF 20% 50V
SE14 2401-000759 E CAPACITOR 220nF 20% 50V
SE15 2401-002180 E CAPACITOR 2.2uF 20% 50V
SE16 2401-001645 E CAPACITOR 0.68uF 20% 50V
SE18 2401-001538 E CAPACITOR 47uF 20% 25V
SE01L 2401-001954 E CAPACITOR 4.7uF 20% 50V
SE01R 2401-001954 E CAPACITOR 4.7uF 20% 50V
SE02L 2401-001538 E CAPACITOR 47uF 20% 25V
SE02R 2401-001538 E CAPACITOR 47uF 20% 25V
SE03L 2401-000438 E CAPACITOR 10uF 20% 25V
SE03R 2401-000438 E CAPACITOR 10uF 20% 25V
SE07L 2401-000438 E CAPACITOR 10uF 20% 25V
SE07R 2401-000438 E CAPACITOR 10uF 20% 25V
SE09L 2401-001938 E CAPACITOR 22uF 20% 25V
SE09R 2401-001938 E CAPACITOR 22uF 20% 25V
SER03 2001-000281 C RESISTOR 100OHM 5% 1/8W
SQ01 KTC2874-B TRANSISTOR 0501-002436
SQ02 KRA104M DIGI TRANSISTOR 0504-001175
SR01 2001-000773 C RESISTOR
470KOHM 5% 1/
8W
SR02 2001-000773 C RESISTOR
470KOHM 5% 1/
8W
SR04 2001-000008 C RESISTOR 15KOHM 5% 1/8W
SR05 2001-000802 C RESISTOR 5.6KOHM 5% 1/8W
SR06 2001-000719 C RESISTOR 4.3KOHM 1% 1/8W
SR07 2001-000273 C RESISTOR
100KOHM 5% 1/
8W
SR08 2001-000290 C RESISTOR 10KOHM 5% 1/8W
SR12 2001-000591 C RESISTOR 3.3KOHM 5% 1/8W
SR13 2001-000023 C RESISTOR 47OHM 5% 1/4W
SR18 2001-000281 C RESISTOR 100OHM 5% 1/8W GB6
SR19 2001-000281 C RESISTOR 100OHM 5% 1/8W
SR20 2001-000244 CARBON RESISTOR
1.5MOHM 5% 1/
8W
SR21 2001-000290 C RESISTOR 10KOHM 5% 1/8W
SR34 2001-000734 C RESISTOR 4.7KOHM 5% 1/8W
SR10L 2001-000331 C RESISTOR 12KOHM 5% 1/8W
SR10R 2001-000331 C RESISTOR 12KOHM 5% 1/8W
SR11L 2001-000449 C RESISTOR 2.2KOHM 5% 1/8W
SR11R 2001-000449 C RESISTOR 2.2KOHM 5% 1/8W
SR14L 2001-000290 C RESISTOR 10KOHM 5% 1/8W
SR14R 2001-000290 C RESISTOR 10KOHM 5% 1/8W
SR16L 2001-000802 C RESISTOR 5.6KOHM 5% 1/8W
SR16R 2001-000802 C RESISTOR 5.6KOHM 5% 1/8W
SZD01 UZ9.1BM Z DIODE 0403-000372
XXXXX AH41-00674A PCB MAIN
 Symbol No. Part No. Part Name Description Local
UIC2 PT8300 IC 0904-001621
UIC3 PT8300 IC 0904-001621
UIC01 LC876780B-53J2 IC AH11-00135A
VR201 3406-001047 SWITCH-ROTARY
5V DC 0.5mA -
12mm
 Symbol No. Part No. Part Name Description Local
